100SXV15M Polymer Capacitors by Panasonic
| Status: | Unknown |
|---|---|
| Series: | - |
| RoHS: | Unknown |
Where to Buy
Prices starting from US$1.13
| Distributor | Stock | ||
|---|---|---|---|
|
element14
from US$2.32
|
500
in stock
|
Buy Now |
|
Farnell
from US$2.15
|
500
in stock
|
Buy Now |
|
TME
from US$1.40
|
195
in stock
|
Buy Now |
|
RS
from US$2.38
|
30
in stock
|
Buy Now |
|
Newark Electronics
from US$2.22
|
0
in stock
|
Buy Now |
|
Future Electronics
from US$2.06
|
0
in stock
|
Buy Now |
|
Avnet America
from US$1.13
|
0
in stock
|
Buy Now |
|
Conrad
from US$2.04
|
0
in stock
|
Buy Now |
|
Schukat Electronic
from US$1.41
|
0
in stock
|
Buy Now |
|
TTI Americas
from US$1.73
|
0
in stock
|
Buy Now |
|
|
TTI Europe
from US$1.53
|
0
in stock
|
Buy Now |
|
|
TTI Asia
from US$1.75
|
0
in stock
|
Buy Now |
|
Ozdisan
from US$1.93
|
0
in stock
|
Buy Now |
|
|
Avnet Asia
-
|
0
in stock
|
Buy Now |
|
Avnet Abacus
-
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Rated Voltage (DC) (V) | 100 |
|---|---|
| Body Type | Surface mount type (vertical mount style) |
| Capacitance (µF) | 15 |
| Polarity Type | Polar |
| E.S.R.-1 (Max. Value) (mΩ) | 40 |
| Rated Ripple Current (Rms) (mA) | 730 |
| Rated Voltage (V) | 100 |
| Leakage Current (Max.) (μA) | 75 |
| Operating Temperature Range (°C) | -55 to 125 |
| Tolerance on Capacitance (%) | -20 to 20 |
| Endurance (h) | 1000 |
| Temperature Range (°C) | -55 to 125 |
| Body Diameter (mm) | 8 |
| Height (Max) (mm) | 12 |
| [email protected] | 1000@125°C |
| Size Code | E12 |
| Rated Ripple Current-1 (mArms) | 2350 |
| Weight (Typ.) (g) | 0.9 |
| Rated Ripple Current-1 (temp.) (°C) | T≦105 |
| Forming & Packaging Feature | Embossed carrier taping (reel packing) |
| Rated Ripple Current-1 (freq.) (kHz) | 100 |
| Rated Ripple Current-2 (mArms) | 730 |
| Rated Ripple Current-2 (temp.) (°C) | 105＜T≦125 |
| Rated Ripple Current-2 (freq.) (kHz) | 100 |
| ESR (mΩ) | 40 |
| ESR Frequency (Hz) | 100 |
| Leakage Current [Max.] (μA) | 75 |
| Dissipation Factor [Max.] | 0.12 |
| Body Length (mm) | 11.9 |
| Minimum packaging quantity (piece) | 400 |
| Weight [Typ.] (g) | 0.88 |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| CAP, 15µF, 100V, 20% | element14 |
| Capacitor: polymer | TME |
| Panasonic 100SXV15M Polymer Capacitor | RS |
| Alum Cap, 15Uf, 100V, 0.73A, Radial, Smd | Newark Electronics |
| SXV Series 100 V 15 uF 125°C 1 K Hrs SMT Aluminum Polymer Capacitor | Future Electronics |
| Panasonic Elektrolyt-Kondensator radial bedrahtet 15 µF 100 V 20 % (Ø) 8 mm 1 St. | Conrad |
| OS-CON SXV 15uF 100V 8x12mm | Schukat Electronic |
| 15UF 100V ESR=40 | TTI Americas |
| 15UF 100V 8X12 SMD | TTI Europe |
| 15UF 100V ESR=40 | TTI Asia |
Frequently Asked Questions
Where can I find additional details, specifications and documents for a 100SXV15M?
Additional datasheets, footprints and schematics for 100SXV15M are listed on our Part Details page. You can also find images and similar parts to 100SXV15M on this page.
What pricing and inventory information can I view?
Distributor pricing and stock information is available for 100SXV15M on our Product Comparison page. Access via the 'View Pricing & Stock' button to view 100SXV15M price breaks, MOQs, lead times, inventory and SKUs from distributors.
What category does 100SXV15M fall under?
The 100SXV15M is listed under Capacitors > Polymer Capacitors > OS-CONâ„¢ Aluminum-Polymer > SXV Series.
Can I view similar or alternative parts?
You can view similar parts to 100SXV15M when available in the SXV Series range under the specifications section at the bottom of the details page.
Who can I contact for technical support of the product?
Submit any questions directly to the customer support team of the distributor listing the product. For the 100SXV15M you can contact the distributor directly for product support, shipping queries etc.
Is the 100SXV15M RoHS compliant?
This part has not been flagged as RoHS Compliant.
Which authorised distributors for 100SXV15M have stock available?
Authorised distributors including element14, Farnell, TME, RS and Newark Electronics have stock available or on a lead time for 100SXV15M.
How do I check stock and lead times for all distributors?
Stock availability and lead times will be displayed for 100SXV15M often in real-time on the comparison pages.
What if I can't find stock of 100SXV15M?
You can fill out our help required form which you can use to request a quote for 100SXV15M from some of our verified obsolescence suppliers. Alternatively, contact us via our web chat in the bottom left of your screen and one of our team will try to help.
