10321071 SPOX by Molex
5.08mm Pitch SPOX Wire-to-Board Header, Vertical, with Friction Lock, 7 Circuits
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
10-32-1071,
0010321071, 5281-07A |
Where to Buy
Prices starting from US$0.41
| Distributor | Stock | ||
|---|---|---|---|
|
Conrad
from US$1.47
|
12,593
in stock
|
Buy Now |
|
Farnell
from US$1.25
|
11,334
in stock
|
Buy Now |
|
Heilind Americas
from US$0.79
|
2,640
in stock
|
Buy Now |
|
TME
from US$0.81
|
250
in stock
|
Buy Now |
|
TTI Europe
from US$0.77
|
250
in stock
|
Buy Now |
|
Newark Electronics
from US$1.08
|
143
in stock
|
Buy Now |
|
element14
from US$0.78
|
143
in stock
|
Buy Now |
|
RS
from US$1.07
|
1
in stock
|
Buy Now |
|
Avnet America
from US$1.01
|
0
in stock
|
Buy Now |
|
|
RS Americas
from US$1.65
|
0
in stock
|
Buy Now |
|
|
TTI Americas
from US$0.78
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.41
|
0
in stock
|
Buy Now |
|
|
TTI Asia
from US$0.79
|
0
in stock
|
Buy Now |
|
EME
from US$0.57
|
0
in stock
|
Buy Now |
|
Offical Electronic
-
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | SPOX |
|---|---|
| Application | Wire-to-Board |
Electrical |
|
|---|---|
| Current Maximum Per Contact | 7.0A |
| Voltage Maximum | 250V |
Physical |
|
|---|---|
| Breakaway | No |
| Circuits Loaded | 7 |
| Circuits Maximum | 7 |
| Color Resin | Natural |
| Durability Mating Cycles Max | 30 |
| First Mate Last Break | No |
| Flammability | 94V-2 |
| Gender | Male |
| Glow Wire Capable | No |
| Guide To Mating Part | No |
| Keying To Mating Part | No |
| Lock To Mating Part | Yes |
| Material Metal | Brass |
| Material Plating Mating | Tin |
| Material Plating Termination | Tin |
| Material Resin | Nylon |
| Mounting Style | Through Hole |
| Net Weight | 2776.300/mg |
| Number Of Rows | 1 |
| Orientation | Vertical |
| Pcb Locator | No |
| Pcb Retention | No |
| Pcb Thickness Recommended | 1.60mm |
| Pc Tail Length | 3.60mm |
| Pitch Mating Interface | 5.08mm |
| Pitch Termination Interface | 5.08mm |
| Plating Min Mating | 5.080µm |
| Plating Min Termination | 5.080µm |
| Polarized To Pcb | No |
| Shrouded | Partially Shrouded |
| Stackable | No |
| Temperature Range Operating | -40° to +105°C |
| Termination Interface Style | Through Hole |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| Molex Einbau-Stiftleiste (Standard) Polzahl Gesamt 7 Rastermaß: 5.08 mm 10321071 1 St. Bag | Conrad |
| CONN, HEADER, 7POS, 1ROW, 5.08MM | Farnell |
| 5.08SPOX FR/LC STR HDR 7C 528 07A | Heilind Americas |
| Connector: wire-board | TME |
| 5.08 MM SPOX HEADER | TTI Europe |
| Conn, Header, 7Pos, 1Row, 5.08Mm Rohs Compliant: Yes |Molex 10-32-1071 | Newark Electronics |
| Molex 10-32-1071 Pin Header | RS |
| Pin Header, Wire-to-Board, 5.08 mm, 1 Rows, 7 Contacts, Through Hole Straight | Avnet America |
| HEADER 5.08MM SPOX WTB, F/LOCK, VERT, 7W | RS Americas |
| SPOX .200 HDR 07P VT | TTI Americas |
Frequently Asked Questions
Where can I find additional details, specifications and documents for a 10321071?
Additional datasheets, footprints and schematics for 10321071 are listed on our Part Details page. You can also find images and similar parts to 10321071 on this page.
What pricing and inventory information can I view?
Distributor pricing and stock information is available for 10321071 on our Product Comparison page. Access via the 'View Pricing & Stock' button to view 10321071 price breaks, MOQs, lead times, inventory and SKUs from distributors.
What category does 10321071 fall under?
The 10321071 is listed under PCB Headers and Receptacles.
Can I view similar or alternative parts?
You can view similar parts to 10321071 when available in the PCB Headers and Receptacles range under the specifications section at the bottom of the details page.
Who can I contact for technical support of the product?
Submit any questions directly to the customer support team of the distributor listing the product. For the 10321071 you can contact the distributor directly for product support, shipping queries etc.
Is the 10321071 RoHS compliant?
Yes. This part has been flagged as RoHS Compliant by Molex.
Which authorised distributors for 10321071 have stock available?
Authorised distributors including Conrad, Farnell, Heilind Americas, TME and TTI Europe have stock available or on a lead time for 10321071.
How do I check stock and lead times for all distributors?
Stock availability and lead times will be displayed for 10321071 often in real-time on the comparison pages.
What if I can't find stock of 10321071?
You can fill out our help required form which you can use to request a quote for 10321071 from some of our verified obsolescence suppliers. Alternatively, contact us via our web chat in the bottom left of your screen and one of our team will try to help.
