1053111203 Nano-Fit by Molex
Nano-Fit Vertical Header, Through Hole, 2.50mm Pitch, Single Row, 3 Circuits, with Solder Clips, 0.38µm Gold (Au) Plating, Black, Glow-Wire Capable, Tray
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: | 105311-1203 |
Where to Buy
Prices starting from US$0.71
| Distributor | Stock | ||
|---|---|---|---|
|
Newark Electronics
from US$1.07
|
2,429
in stock
|
Buy Now |
|
TME
from US$0.99
|
2,429
in stock
|
Buy Now |
|
Conrad
from US$1.36
|
2,429
in stock
|
Buy Now |
|
Farnell
from US$1.13
|
2,187
in stock
|
Buy Now |
|
RS
from US$1.82
|
0
in stock
|
Buy Now |
|
Sager
from US$0.71
|
0
in stock
|
Buy Now |
|
Heilind Americas
from US$0.73
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.76
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | Nano-Fit |
|---|---|
| Application | Wire-to-Board |
Electrical |
|
|---|---|
| Current Maximum Per Contact | 7.5A |
| Voltage Maximum | 250V AC (RMS)/DC |
Physical |
|
|---|---|
| Breakaway | No |
| Circuits Loaded | 3 |
| Circuits Maximum | 3 |
| Color Resin | Black |
| Durability Mating Cycles Max | 50 |
| First Mate Last Break | No |
| Glow Wire Capable | Yes |
| Guide To Mating Part | No |
| Keying To Mating Part | Yes |
| Lock To Mating Part | Yes |
| Material Metal | Brass |
| Material Plating Mating | Gold |
| Material Plating Termination | Tin |
| Material Resin | Liquid Crystal Polymer (LCP) |
| Net Weight | 0.490/g |
| Number Of Rows | 1 |
| Orientation | Vertical |
| Packaging Alternative Part | Array |
| Pcb Locator | Yes |
| Pcb Retention | Yes |
| Pcb Thickness Recommended | 1.60mm, 2.40mm |
| Pc Tail Length | 3.20mm |
| Pitch Mating Interface | 2.50mm |
| Pitch Termination Interface | 2.50mm |
| Plating Min Mating | 0.381µm |
| Plating Min Termination | 1.524µm |
| Polarized To Mating Part | Yes |
| Polarized To Pcb | Yes |
| Shrouded | Shrouded |
| Stackable | No |
| Temperature Range Operating | -40° to +125°C |
| Termination Interface Style | Through Hole |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| Nanofit Hdr Vrt 3Ckt Sr Sldrclip Blk 15Au |Molex 105311-1203 | Newark Electronics |
| Connector: wire-board | TME |
| Molex Einbau-Buchsenleiste (Standard) Polzahl Gesamt 3 Rastermaß: 2.50 mm 1053111203 1 St. Tray | Conrad |
| NANOFIT HDR VRT 3CKT SR SLDRCLIP BL | Farnell |
| Molex 105311-1203 PCB Header | RS |
| Headers & Wire Housings NANO-FIT HDR 01X03P 15AU VT | Sager |
| NANO-FIT HDR VT SGL FRK 3CKT 15AU BLK | Heilind Americas |
