10977085 C-Grid by Molex
2.54mm Pitch C-Grid Breakaway Header, Dual Row, Vertical, High Temperature, 8 Circuits, Tin (Sn) Plating, 2.79mm PC Tail Length
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
10-97-7085,
0010977085, A-70280-0124 |
Where to Buy
Prices starting from US$0.26
| Distributor | Stock | ||
|---|---|---|---|
|
Newark Electronics
from US$0.41
|
3,614
in stock
|
Buy Now |
|
Conrad
from US$0.72
|
3,614
in stock
|
Buy Now |
|
Farnell
from US$0.68
|
3,253
in stock
|
Buy Now |
|
RS
from US$0.70
|
0
in stock
|
Buy Now |
|
Avnet America
from US$0.32
|
0
in stock
|
Buy Now |
|
|
RS Americas
from US$0.41
|
0
in stock
|
Buy Now |
|
Sager
from US$0.32
|
0
in stock
|
Buy Now |
|
Heilind Americas
from US$0.30
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.26
|
0
in stock
|
Buy Now |
|
Avnet Abacus
-
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | C-Grid |
|---|---|
| Application | Board-to-Board, Wire-to-Board |
Electrical |
|
|---|---|
| Current Maximum Per Contact | 3.0A |
| Voltage Maximum | 250V |
Physical |
|
|---|---|
| Breakaway | Yes |
| Circuits Loaded | 8 |
| Circuits Maximum | 8 |
| Color Resin | Black |
| Durability Mating Cycles Max | 25 |
| First Mate Last Break | No |
| Flammability | 94V-0 |
| Glow Wire Capable | No |
| Guide To Mating Part | No |
| Keying To Mating Part | No |
| Lock To Mating Part | No |
| Material Metal | Copper Alloy |
| Material Plating Mating | Tin |
| Material Plating Termination | Tin |
| Material Resin | High Temperature Thermoplastic |
| Net Weight | 0.557/g |
| Number Of Rows | 2 |
| Orientation | Vertical |
| Pcb Locator | No |
| Pcb Retention | No |
| Pcb Thickness Recommended | 1.60mm |
| Pc Tail Length | 2.79mm |
| Pitch Mating Interface | 2.54mm |
| Plating Min Mating | 3.810µm |
| Plating Min Termination | 3.810µm |
| Polarized To Mating Part | No |
| Polarized To Pcb | No |
| Shrouded | Unshrouded |
| Stackable | Yes |
| Temperature Range Operating | -40° to +105°C |
| Termination Interface Style | Through Hole |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| Header Connector, pcb Mount, recept,8 Contacts, pin,0.1 Pitch, pc Tail Terminal |Molex 10-97-7085 | Newark Electronics |
| Molex Stiftleiste (Standard) Anzahl Reihen: 2 10977085 1 St. Bulk | Conrad |
| CONN, HEADER, 8POS, 2ROW, 2.54MM, TH | Farnell |
| Molex 10-97-7085 PCB Header | RS |
| Conn Unshrouded Header HDR 8 POS 2.54mm Solder ST Thru-Hole Bag | Avnet America |
| CGRID VT BKWY HDR TIN 8CKT 320110 | RS Americas |
| Headers & Wire Housings CGrid VT Bkwy Hdr Tin 8Ckt 320110 | Sager |
| CGRID VT BKWY HDR TIN 8CKT (3 0/110) | Heilind Americas |
