1200790232 M12 Signal Push-Pull,Ultra-Lock (M12) by Molex
M12 Signal, A-Coded, M12 Push-Pull Ultra-Lock Single-Ended Cordset, 4 Poles, Female (90°) to Pigtail, 22 AWG, Yellow PVC Cable, 2.0m (6.56') Length
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
120079-0232,
W04001A09M020 |
Where to Buy
Prices starting from US$28.08
| Distributor | Stock | ||
|---|---|---|---|
|
Farnell
from US$79.62
|
5
in stock
|
Buy Now |
|
Newark Electronics
from US$37.28
|
0
in stock
|
Buy Now |
|
Avnet America
from US$29.51
|
0
in stock
|
Buy Now |
|
RS Americas
from US$45.20
|
0
in stock
|
Buy Now |
|
element14
from US$28.08
|
0
in stock
|
Buy Now |
|
Sager
from US$30.39
|
0
in stock
|
Buy Now |
|
Heilind Americas
from US$29.91
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
-
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | M12 Signal Push-Pull,Ultra-Lock (M12) |
|---|
Electrical |
|
|---|---|
| Current Maximum Per Contact | 4.0A |
| Voltage Maximum | 250V AC/DC |
Physical |
|
|---|---|
| Cable Diameter | 5.10mm (.201") |
| Cable Length | 2.0m (6.56') |
| Color Cable Jacket | Yellow |
| Connector End A | M12 Signal Push-Pull |
| Connector End B | Pigtail |
| Coupling Style | Push-Pull |
| Gender | Female-Pigtail |
| Key Way | A-Coded |
| Led Indicator | None |
| Material Cable Jacket | PVC |
| Material Connector Body | PUR |
| Material Contact | Copper Alloy |
| Material Coupling Nut | Nickel-plated Brass |
| Material Oring | Fluoro-elastomer |
| Material Plating Mating | Gold |
| Net Weight | 251.000/g |
| Orientation | 90° to Pigtail |
| Poles | 4 |
| Temperature Range Operating | -25° to +90°C |
| Wire Cable Type | UL 2661 |
| Wire Size Awg | 22 |
Last 6 months Inventory & Pricing History
120079-0232 Sensors & Transducers by Molex
SENSOR CORD 4P M12 RCPT-FREE END 2M
| Status: | Unknown |
|---|---|
| Series: | Ultra-Lock 120079 Series |
| RoHS: | Unknown |
Specifications
| Connector Type A | M12 Sensor Right Angle 4 Position Receptacle |
|---|---|
| Connector Type B | Free End |
| Cable Length - Metric | 2m |
| Cable Length - Imperial | 6.56ft |
| Product Range | Ultra-Lock 120079 Series |
| SVHC | No SVHC (17-Dec-2015) |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| SENSOR | Farnell |
| Sensor Cord, 4P, M12 Rcpt-Pigtail, 2M | Newark Electronics |
| Ultra-Lock Single-Ended Cordset 4 Position Female Right Angle 22 AWG PVC 2m | Avnet America |
| MIC 4P FP ULOCK 2M 90D 22/4PVC | RS Americas |
| SENSOR CORD, 4P, M12 RCPT-FREE END, 2M | element14 |
| Sensor Cables / Actuator Cables ULTRA-LOCK M12 SNGLEND CORDSET | Sager |
