1300620128 BradPower A-Size by Molex
BradPower A-Size (7/8”–M22) Double-Ended Cordset, 4 Poles, Male (Straight) to Female (Straight), 14 AWG, Gray PVC Cable, 5.0m (16.40') Length
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
130062-0128,
114030A46M050 |
Specifications
| Product Name | BradPower A-Size |
|---|
Electrical |
|
|---|---|
| Current Maximum Per Contact | 10.0A |
| Voltage Maximum | 600V |
Physical |
|
|---|---|
| Cable Diameter | 14.85mm (.585") |
| Cable Length | 5.0m (16.40') |
| Color Cable Jacket | Gray |
| Connector End A | BradPower A-Size (7/8”–M22) |
| Connector End B | BradPower A-Size (7/8”–M22) |
| Coupling Style | Threaded |
| Gender | Female-Male |
| Key Way | Single |
| Led Indicator | None |
| Material Cable Jacket | PVC |
| Material Connector Body | TPE |
| Material Contact | Copper Alloy |
| Material Coupling Nut | Black Epoxy Coated Zinc |
| Material Plating Mating | Gold |
| Net Weight | 544.000/g |
| Orientation | Straight to Straight |
| Poles | 4 |
| Temperature Range Operating | -20° to +105°C |
| Wire Cable Type | STOOW |
| Wire Size Awg | 14 |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| Power Cord, Circular Plug, 5M, 15A, Gray | Newark Electronics |
| BP A 4P M/MFE SK ST 14 GY PVC | Heilind Americas |
