1727040195 FCT Products by Molex
FCT Plastic Backshell for D-Sub Connector, Shielded, Shell Size 3, Straight Cable Outlet, IP67 Waterproof, with #4-40 Locking Screws, Individual Packing
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
172704-0195,
FWA3GAE |
Where to Buy
Prices starting from US$12.44
| Distributor | Stock | ||
|---|---|---|---|
|
Rutronik
from US$17.02
|
0
in stock
|
Buy Now |
|
Newark Electronics
from US$16.63
|
0
in stock
|
Buy Now |
|
Compona
from US$13.05
|
0
in stock
|
Buy Now |
|
Conrad
from US$21.50
|
0
in stock
|
Buy Now |
|
TTI Europe
from US$14.77
|
0
in stock
|
Buy Now |
|
Sager
from US$14.09
|
0
in stock
|
Buy Now |
|
Heilind Americas
from US$13.86
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$12.44
|
0
in stock
|
Buy Now |
|
Farnell
from US$16.16
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | FCT Products |
|---|
Electrical |
|
|---|---|
| Shielded | Yes |
| Shield Type | Shielded Plastic |
Physical |
|
|---|---|
| Cable Diameter | 8.00-10.50mm |
| Material Backshell | PC+ABS |
| Material Screw | Brass |
| Material Seal | Elastomer |
| Mounting Style | Locking Screw |
| Net Weight | 57.000/g |
| Orientation | Straight |
| Plating Back Shell | Nickel |
| Temperature Range Operating | -25° to +70°C |
| Thread Size | 4-40 UNC |
| Thread Type | Standard |
| Tightening Test Torque | 40 Ncm |
| Waterproof Dustproof | Yes |
| Waterproof Dustproof Type | IP67 |
| Shell Size | 3 |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| FCT BACKSHELL PLASTIC SIZE 3 W SCREWLOCK | Rutronik |
| Fct Hood S3 0 Deg Shld Plstc W/Scrwlck Rohs Compliant: Yes |Molex 172704-0195 | Newark Electronics |
| MOLEX FWA3GAE Plastic hood IP67, 25p | Compona |
| Molex 1727040195 D-SUB Gehäuse Kunststoff 180 ° 1 St. | Conrad |
| FCT WD HOOD S3 0 DEG SHLD | TTI Europe |
| D-Sub Standard Connectors FCT WD HOOD S3 0 DEG SHLD PLSTC W/SCRW | Sager |
| FWA3GAE FCT HOOD S3 0 DEG SHLD PLSTC W/SCRWLCK | Heilind Americas |
| D-SUB BACKSHELL, DB, 180°, PET | Farnell |
172704-0195 Connectors by FCT ELECTRONIC gmbh
D-SUB BACKSHELL DB 180° PET
| Status: | Unknown |
|---|---|
| Series: | 172704 Series |
| RoHS: | Unknown |
Specifications
| Product Range | 172704 Series |
|---|---|
| D Sub Shell Size | DB |
| Cable Exit Angle | 180° |
| Connector Body Material | PET (Polyester) Body |
