1727040199 FCT Products by Molex
FCT Plastic Backshell for D-Sub Connector, Shielded, Shell Size 5, Straight Cable Outlet, IP67 Waterproof, with #4-40 Locking Screws, Individual Packing
| Status: | Obsolete |
|---|---|
| Series: | - |
| RoHS: | Unknown |
| Aliases: |
172704-0199,
FWA5GAE |
Specifications
| Product Name | FCT Products |
|---|
Electrical |
|
|---|---|
| Shielded | Yes |
| Shield Type | Shielded Plastic |
Physical |
|
|---|---|
| Cable Diameter | 9.00-11.00mm |
| Material Backshell | PC+ABS |
| Material Screw | Brass |
| Material Seal | Elastomer |
| Mounting Style | Locking Screw |
| Net Weight | 47.100/g |
| Orientation | Straight |
| Plating Back Shell | Nickel |
| Temperature Range Operating | -25° to +70°C |
| Thread Size | 4-40 UNC |
| Thread Type | Standard |
| Tightening Test Torque | 40 Ncm |
| Waterproof Dustproof | Yes |
| Waterproof Dustproof Type | IP67 |
| Shell Size | 5 |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| Fct Wd Hood S5 0 Deg Shld Plstc W/Scrw |Molex 172704-0199 | Newark Electronics |
| MOLEX FWA5GAE Plastic hood IP67, 50p | Compona |
| Molex 1727040199 D-SUB Gehäuse Kunststoff 180 ° 1 St. | Conrad |
| D-Sub Backshells FCT WD HOOD S5 0 DEG SHLD PLSTC W/SCRW | Sager |
| D SUB BACKSHELL, SHIELDED, SIZE DD | Farnell |
172704-0199 Connectors by FCT ELECTRONIC gmbh
D SUB BACKSHELL SHIELDED SIZE DD
| Status: | Unknown |
|---|---|
| Series: | FWA Series |
| RoHS: | Unknown |
Specifications
| Product Range | FWA Series |
|---|---|
| D Sub Shell Size | DD |
| Cable Exit Angle | 180° |
| Connector Body Material | PET (Polyester) Body |
