1731070098 FCT Products by Molex
FCT Mixed Layout D-Sub Connector, Male, Right-Angle, PCB Through Hole, Gold Plating, Tin-plated Shell with Dimples, 9 Circuits Max, 5 Signal Contacts Loaded, Green Insulator
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
173107-0098,
FM9W4P5-K120 |
Where to Buy
Prices starting from US$1.63
| Distributor | Stock | ||
|---|---|---|---|
|
RS
from US$8.24
|
120
in stock
|
Buy Now |
|
Newark Electronics
from US$1.63
|
11
in stock
|
Buy Now |
|
element14
from US$9.00
|
11
in stock
|
Buy Now |
|
Farnell
from US$7.61
|
11
in stock
|
Buy Now |
|
Offical Electronic
-
|
31
in stock
|
Buy Now |
|
Rutronik
from US$8.59
|
0
in stock
|
Buy Now |
|
Compona
from US$6.84
|
0
in stock
|
Buy Now |
|
Sager
from US$5.20
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | FCT Products |
|---|
Electrical |
|
|---|---|
| Current Maximum Per Contact | 7.5A |
| Shielded | Yes |
Physical |
|
|---|---|
| Circuits Loaded | 5 |
| Circuits Maximum | 9 |
| Color Resin | Green |
| Gender | Male |
| Material Contact | Copper Alloy |
| Material Resin | Polybutylene Terephthalate (PBT) |
| Material Shell | Steel |
| Net Weight | 8.000/g |
| Number Of Rows | 2 |
| Orientation | Right Angle |
| Panel Mount | Rear |
| Panel Mount Method | Flange |
| Pcb Locator | No |
| Pcb Retention | No |
| Pcb Thickness Recommended | 1.60mm |
| Pc Tail Length | 11.10mm |
| Pitch Mating Interface | 2.84mm |
| Pitch Termination Interface | 2.54mm |
| Plating Contact | Gold over Nickel |
| Plating Shell | Tin |
| Polarized To Mating Part | Yes |
| Polarized To Pcb | Yes |
| Ports | 1 |
| Temperature Range Operating | -55° to +130°C |
| Termination Style | Through Hole |
| Waterproof Dustproof | No |
| Waterproof Dustproof Type | IP20 |
| Shell Size | 3 |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| PLUG RIGHT ANGLE 9W4 | RS |
| Fct Ml Dsub Ra Pc Plg 9W4 Rohs Compliant: Yes |Molex/fct 173107-0098 | Newark Electronics |
| FCT ML DSUB RA PC PLG 9W4 99AC4888 | element14 |
| 9W4 D-Sub Mixed-Layout Male 90° | Rutronik |
| MOLEX FM9W4P5-K120 D-Sub Male connector shell Mixed Layout | Compona |
| D-Sub Mixed Contact Connectors FCT ML DSUB RA PC PLG 9W4 | Sager |
