1731090591 FCT Products by Molex
FCT Standard-Density D-Sub Connector, Female, Right-Angle, PCB Through Hole, 11.10mm Tail Length, Gold Plating, 200 Mating Cycles, 37 Circuits, White Insulator
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
173109-0591,
F37S5G2 |
Where to Buy
Prices starting from US$3.69
| Distributor | Stock | ||
|---|---|---|---|
|
Newark Electronics
from US$3.69
|
9
in stock
|
Buy Now |
|
element14
from US$13.66
|
9
in stock
|
Buy Now |
|
Farnell
from US$12.46
|
9
in stock
|
Buy Now |
|
Offical Electronic
-
|
25
in stock
|
Buy Now |
|
Compona
from US$12.00
|
0
in stock
|
Buy Now |
|
Sager
from US$9.33
|
0
in stock
|
Buy Now |
|
Heilind Americas
from US$11.58
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$11.52
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | FCT Products |
|---|
Electrical |
|
|---|---|
| Current Maximum Per Contact | 7.5A |
| Shielded | Yes |
Physical |
|
|---|---|
| Circuits Loaded | 37 |
| Circuits Maximum | 37 |
| Color Resin | White |
| Gender | Female |
| Material Contact | Copper Alloy |
| Material Resin | Polybutylene Terephthalate (PBT) |
| Material Shell | Steel |
| Net Weight | 19.400/g |
| Number Of Rows | 2 |
| Orientation | Right Angle |
| Panel Mount | Rear |
| Panel Mount Method | Flange |
| Pcb Locator | No |
| Pcb Retention | No |
| Pcb Thickness Recommended | 1.60mm |
| Pc Tail Length | 11.10mm |
| Pitch Mating Interface | 2.84mm |
| Pitch Termination Interface | 2.54mm |
| Plating Contact | Gold over Nickel |
| Plating Shell | Tin |
| Polarized To Mating Part | Yes |
| Polarized To Pcb | Yes |
| Ports | 1 |
| Temperature Range Operating | -55° to +125°C |
| Termination Style | Through Hole |
| Waterproof Dustproof | No |
| Waterproof Dustproof Type | IP20 |
| Shell Size | 4 |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| Fct Dsub Ra Pc Rcpt 37 Pn Rohs Compliant: Yes |Molex/fct 173109-0591 | Newark Electronics |
| FCT DSUB RA PC RCPT 37 PN 99AC5261 | element14 |
| MOLEX F37S5G2 D-Sub Connector female 37p, 90° | Compona |
| D-Sub Standard Connectors FCT DSUB RA PC RCPT 37 PN | Sager |
| F37S5G2 FCT DSUB RA PC RCPT 37 PN | Heilind Americas |
