1731140106 FCT Products by Molex
FCT Standard-Density Dual-Port D-Sub Connector, Female, Right-Angle, PCB Through Hole, 9.40mm Tail Length, Gold Plating, 200 Mating Cycles, Medium Mounting Height, Snap-in Bolt, 9 Circuits per Port, Black Insulator
| Status: | Obsolete |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
173114-0106,
FDT09SG2M |
Specifications
| Product Name | FCT Products |
|---|
Electrical |
|
|---|---|
| Current Maximum Per Contact | 5.0A |
| Shielded | Yes |
Physical |
|
|---|---|
| Circuits Loaded | 18 |
| Circuits Maximum | 18 |
| Color Resin | Black |
| Gender | Female |
| Material Contact | Copper Alloy |
| Material Resin | Polybutylene Terephthalate (PBT) |
| Material Shell | Steel |
| Net Weight | 17.800/g |
| Number Of Rows | 4 |
| Orientation | Right Angle |
| Panel Mount | Rear |
| Panel Mount Method | Thread-In |
| Pcb Locator | Yes |
| Pcb Retention | Yes |
| Pcb Thickness Recommended | 1.60mm |
| Pc Tail Length | 9.40mm |
| Pitch Mating Interface | 2.84mm |
| Pitch Termination Interface | 2.54mm |
| Plating Contact | Gold over Nickel |
| Plating Shell | Tin |
| Polarized To Mating Part | Yes |
| Polarized To Pcb | Yes |
| Ports | 2 |
| Temperature Range Operating | -55° to +130°C |
| Termination Style | Through Hole |
| Waterproof Dustproof | No |
| Waterproof Dustproof Type | IP20 |
| Shell Size | 1 |
