2132260210 CLIK-Mate by Molex
1.50mm Pitch CLIK-Mate Wire-to-Board PCB Receptacle, Single Row, Surface Mount, Right-Angle, 0.10µm Gold (Au) Plating, 2 Circuits, Natural
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: | 213226-0210 |
Where to Buy
Prices starting from US$0.44
| Distributor | Stock | ||
|---|---|---|---|
|
Conrad
from US$1.03
|
24,000
in stock
|
Buy Now |
|
Farnell
from US$0.70
|
21,600
in stock
|
Buy Now |
|
Newark Electronics
from US$0.63
|
19,000
in stock
|
Buy Now |
|
TME
from US$0.58
|
19,000
in stock
|
Buy Now |
|
element14
from US$0.72
|
2,190
in stock
|
Buy Now |
|
RS
from US$0.70
|
0
in stock
|
Buy Now |
|
Avnet America
from US$0.48
|
0
in stock
|
Buy Now |
|
|
RS Americas
from US$0.81
|
0
in stock
|
Buy Now |
|
TTI Americas
from US$0.44
|
0
in stock
|
Buy Now |
|
Sager
from US$0.45
|
0
in stock
|
Buy Now |
|
Heilind Americas
from US$0.45
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.51
|
0
in stock
|
Buy Now |
|
|
TTI Asia
from US$0.68
|
0
in stock
|
Buy Now |
|
Avnet Abacus
-
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | CLIK-Mate |
|---|---|
| Application | Wire-to-Board |
Electrical |
|
|---|---|
| Current Maximum Per Contact | 2.0A |
| Voltage Maximum | 100V AC (RMS)/DC |
Physical |
|
|---|---|
| Circuits Loaded | 2 |
| Circuits Maximum | 2 |
| Color Resin | Natural |
| Durability Mating Cycles Max | 30 |
| First Mate Last Break | No |
| Gender | Female |
| Glow Wire Capable | No |
| Guide To Mating Part | Yes |
| Keying To Mating Part | Yes |
| Lock To Mating Part | Yes |
| Material Metal | Copper Alloy |
| Material Plating Mating | Gold |
| Material Plating Termination | Tin |
| Material Resin | Polyamide (PA) |
| Net Weight | 391.000/mg |
| Number Of Rows | 1 |
| Orientation | Right Angle |
| Pcb Locator | No |
| Pcb Retention | Yes |
| Pitch Mating Interface | 1.50mm |
| Pitch Termination Interface | 1.50mm |
| Plating Min Mating | 0.102µm |
| Plating Min Termination | 0.102µm |
| Polarized To Mating Part | Yes |
| Polarized To Pcb | No |
| Stackable | No |
| Temperature Range Operating | -40° to +105°C |
| Termination Interface Style | Surface Mount |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| Molex Buchsengehäuse-Platine Polzahl Gesamt 2 Rastermaß: 1.50 mm 2132260210 1 St. Tape | Conrad |
| CONN, R/A RCPT, 2POS, 1.5MM, SMT | Farnell |
| Clik-Mate1.5 Srra Smt Au0.1 Etp 2P Nat Rohs Compliant: Yes |Molex 213226-0210 | Newark Electronics |
| Contact | TME |
| WTB CONN, RCPT, R/A, 2POS, 1ROW, 1.5MM | element14 |
| 1.50mm Pitch CLIK-Mate Wire-to-Board PCB | RS |
| Conn Wire to Board RCP 2 POS 1.5mm Solder RA SMD Emboss T/R | Avnet America |
| CONNECTOR, 1.5 MM PITCH CLIK-MATE, RIGHT-ANGLE, 0.10M GOLD (AU) PLATING | RS Americas |
| 1.50MM CLIK-MATE REC 02P RA AU | TTI Americas |
| Headers & Wire Housings 1.50MM CLIK-MATE REC 02P RA AU | Sager |
| CLIK-MATE1.5 SRRA SMT AU0.1 ET | Heilind Americas |
Frequently Asked Questions
Where can I find additional details, specifications and documents for a 2132260210?
Additional datasheets, footprints and schematics for 2132260210 are listed on our Part Details page. You can also find images and similar parts to 2132260210 on this page.
What pricing and inventory information can I view?
Distributor pricing and stock information is available for 2132260210 on our Product Comparison page. Access via the 'View Pricing & Stock' button to view 2132260210 price breaks, MOQs, lead times, inventory and SKUs from distributors.
What category does 2132260210 fall under?
The 2132260210 is listed under PCB Headers and Receptacles.
Can I view similar or alternative parts?
You can view similar parts to 2132260210 when available in the PCB Headers and Receptacles range under the specifications section at the bottom of the details page.
Who can I contact for technical support of the product?
Submit any questions directly to the customer support team of the distributor listing the product. For the 2132260210 you can contact the distributor directly for product support, shipping queries etc.
Is the 2132260210 RoHS compliant?
Yes. This part has been flagged as RoHS Compliant by Molex.
Which authorised distributors for 2132260210 have stock available?
Authorised distributors including Conrad, Farnell, Newark Electronics, TME and element14 have stock available or on a lead time for 2132260210.
How do I check stock and lead times for all distributors?
Stock availability and lead times will be displayed for 2132260210 often in real-time on the comparison pages.
What if I can't find stock of 2132260210?
You can fill out our help required form which you can use to request a quote for 2132260210 from some of our verified obsolescence suppliers. Alternatively, contact us via our web chat in the bottom left of your screen and one of our team will try to help.
