2290200-R More Semiconductors - ICs by Microchip Technology
12G SAS/SATA PCIe® Gen 3 RAID Adapter
| Status: | Active |
|---|---|
| Series: | SmartRAID-3152-8i |
| RoHS: | Unknown |
The 12 Gbps Adaptec SmartRAID 3152-8i RAID adapter has 8 internal SAS/SATA ports in a x8 PCIe Gen 3 low-profile, MD2 form factor. Microchip's industry leading Smart Storage stack delivers maximum reliability and best-in-class performance that all RAID levels come to expect, plus unique features like Mixed Mode support (RAID and HBA devices can be used simultaneously), adapter power management (reduces power consumption up to 30 percent), and Advanced Data Management (ADM) features that allow data migration from existing RAID arrays.
SmartRAID 3152-8i adapters include maxCache 4.0, and when coupled with 12 Gbps SSDs, provide maximum read/write bandwidth and IOPS as well as acceleration and latency optimization through caching. The SmartRAID 3152-8i adapters also integrate flash-based cache backup to enable instant cache protection. The tethered ASCM-35F capacitor module ensures data is safely backed up to Flash memory in case of power loss.
With broad operating system support and ecosystem compatibility, SmartRAID adapters are easy to implement and scale, and the unified maxView management tools and drivers across the Microchip HBA, RAID, and expander solutions enable easy manageability across the entire product line.
The SmartRAID 3152 RAID adapter is an ideal solution for high performance enterprise servers that require maximum connectivity and security.
Where to Buy
Prices starting from US$916.79
Specifications
| Product Type | RAID Adapter |
|---|---|
| Port Count | 8 internal |
| Interface | 8-Lane PCIe Gen 3 |
| RAID Level | Hardware RAID 0, 1, 5, 6, 10, 50, 60, 1 ADM and 10 ADM |
| Physical Dimensions | 2.535\" H x 6.6\" L(64 mm x 167 mm) |
| Form Factor | Low-profile, MD2 |
| Controller | 12 Gbps SmartROC 3100 |
| Connectors | 2 (x4) SFF-8643 |
| Cache | 2 GB DDR4/2100 MHz |
| SSD Cache Protection | maxCache 4.0 |
| Cache Protection | Embedded Flash backup, Tethered ASCM-35 supercap |
Last 6 months Inventory & Pricing History
Resources
Brochures |
|---|
| Adaptec SmartRAID 3100 |
| Adaptec® Storage Board Solutions Brochure |
| Adaptec HD Cables |
| Top 10 Tips |
Environmental Information
| ROHS | Unknown |
|---|---|
| China EFUP | Unknown |
Alternative Descriptions
| Microchip 2290200-R Adapter | RS |
| Smartraid 3152-8I Single Rohs Compliant: Yes |Microchip Technology 2290200-R | Newark Electronics |
| SmartRAID 3100 Adapter with 8 Internal SAS/SATA Ports in LP/MD2 2 GB DDR4 12 Gbps ROC | Avnet America |
| SmartRAID 3152-8i SINGLE | Microchip Technology |
