310731010 H-DAC 64 by Molex
2.54mm H-DAC 64, 6 Way Receptacle Assembly, Single Row, Polarization A
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
31073-1010,
0310731010 |
Where to Buy
Prices starting from US$0.07
| Distributor | Stock | ||
|---|---|---|---|
|
TME
from US$0.24
|
34,680
in stock
|
Buy Now |
|
Conrad
from US$0.86
|
34,680
in stock
|
Buy Now |
|
Farnell
from US$0.66
|
31,212
in stock
|
Buy Now |
|
TTI Americas
from US$0.44
|
22,000
in stock
|
Buy Now |
|
Newark Electronics
from US$0.07
|
114
in stock
|
Buy Now |
|
RS
from US$0.43
|
0
in stock
|
Buy Now |
|
Avnet America
from US$0.47
|
0
in stock
|
Buy Now |
|
|
RS Americas
from US$0.64
|
0
in stock
|
Buy Now |
|
element14
from US$0.52
|
0
in stock
|
Buy Now |
|
Heilind Americas
from US$0.49
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.22
|
0
in stock
|
Buy Now |
|
|
TTI Asia
from US$0.27
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | H-DAC 64 |
|---|---|
| Application | Automotive, Wire-to-Board, Wire-to-Wire |
Physical |
|
|---|---|
| Circuits Maximum | 6 |
| Color Resin | Black, White |
| Gender | Receptacle |
| Glow Wire Capable | No |
| Keying To Mating Part | No |
| Lock To Mating Part | Yes |
| Material Resin | Modified Polystyrene, Polyester |
| Net Weight | 1.600/g |
| Number Of Rows | 1 |
| Panel Mount | No |
| Pitch Mating Interface | 2.54mm |
| Pitch Termination Interface | 2.54mm |
| Polarized To Mating Part | Yes |
| Ports | 1 |
| Stackable | No |
| Temperature Range Operating | -40° to +100°C |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| Connector: automotive | TME |
| Molex Buchsengehäuse-Kabel 310731010 1 St. Bulk | Conrad |
| CONNECTOR HOUSING, RCPT, 6POS, 2.54MM | Farnell |
| HDAC64 2.54MM 01X06P BLK | TTI Americas |
| Hdac64 Sr Female 6 Ckt Black Pol 1 Rohs Compliant: Yes |Molex 31073-1010 | Newark Electronics |
| Molex 31073-1010 Connector Housing | RS |
| H-DAC 64 SERIES 2.54MM PITCH 6 WAY 1 ROW FEMALE STRAIGHT PCB HOUSING 31073 | RS Americas |
| HDAC64 SR FEMALE 6 CKT BLACK OL 1 | Heilind Americas |
Frequently Asked Questions
Where can I find additional details, specifications and documents for a 310731010?
Additional datasheets, footprints and schematics for 310731010 are listed on our Part Details page. You can also find images and similar parts to 310731010 on this page.
What pricing and inventory information can I view?
Distributor pricing and stock information is available for 310731010 on our Product Comparison page. Access via the 'View Pricing & Stock' button to view 310731010 price breaks, MOQs, lead times, inventory and SKUs from distributors.
What category does 310731010 fall under?
The 310731010 is listed under Connector Housings.
Can I view similar or alternative parts?
You can view similar parts to 310731010 when available in the Connector Housings range under the specifications section at the bottom of the details page.
Who can I contact for technical support of the product?
Submit any questions directly to the customer support team of the distributor listing the product. For the 310731010 you can contact the distributor directly for product support, shipping queries etc.
Is the 310731010 RoHS compliant?
Yes. This part has been flagged as RoHS Compliant by Molex.
Which authorised distributors for 310731010 have stock available?
Authorised distributors including TME, Conrad, Farnell, TTI Americas and Newark Electronics have stock available or on a lead time for 310731010.
How do I check stock and lead times for all distributors?
Stock availability and lead times will be displayed for 310731010 often in real-time on the comparison pages.
What if I can't find stock of 310731010?
You can fill out our help required form which you can use to request a quote for 310731010 from some of our verified obsolescence suppliers. Alternatively, contact us via our web chat in the bottom left of your screen and one of our team will try to help.
