39301039 Mini-Fit Jr. by Molex
Mini-Fit Jr. Vertical Header, 4.20mm Pitch, Single Row, 3 Circuits, with Snap-in Plastic Peg PCB Lock, Tin, Natural
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
39-30-1039,
0039301039, A-5566-03A3 |
Where to Buy
Prices starting from US$0.22
| Distributor | Stock | ||
|---|---|---|---|
|
Heilind Americas
from US$0.26
|
50,216
in stock
|
Buy Now |
|
TTI Americas
from US$0.33
|
38,594
in stock
|
Buy Now |
|
Newark Electronics
from US$0.40
|
35,722
in stock
|
Buy Now |
|
Farnell
from US$0.55
|
26,277
in stock
|
Buy Now |
|
|
TTI Europe
from US$0.42
|
16,146
in stock
|
Buy Now |
|
Rutronik
from US$0.50
|
12,219
in stock
|
Buy Now |
|
element14
from US$0.50
|
11,447
in stock
|
Buy Now |
|
Schukat Electronic
from US$0.45
|
5,727
in stock
|
Buy Now |
|
EME
from US$0.60
|
3,844
in stock
|
Buy Now |
|
Rapid Electronics
from US$0.60
|
2,650
in stock
|
Buy Now |
|
Conrad
from US$0.56
|
2,650
in stock
|
Buy Now |
|
RS
from US$0.64
|
1,805
in stock
|
Buy Now |
|
TME
from US$0.74
|
460
in stock
|
Buy Now |
|
|
RS Americas
from US$0.22
|
114
in stock
|
Buy Now |
|
Offical Electronic
-
|
1,700
in stock
|
Buy Now |
|
Avnet America
from US$0.35
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.49
|
0
in stock
|
Buy Now |
|
|
TTI Asia
from US$0.45
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | Mini-Fit Jr. |
|---|---|
| Application | Wire-to-Board |
Electrical |
|
|---|---|
| Current Maximum Per Contact | 9.0A |
| Voltage Maximum | 600V |
Physical |
|
|---|---|
| Breakaway | No |
| Circuits Loaded | 3 |
| Circuits Maximum | 3 |
| Color Resin | Natural |
| Durability Mating Cycles Max | 30 |
| First Mate Last Break | No |
| Flammability | 94V-2 |
| Glow Wire Capable | No |
| Guide To Mating Part | No |
| Keying To Mating Part | No |
| Lock To Mating Part | Yes |
| Material Metal | Brass |
| Material Plating Mating | Tin |
| Material Plating Termination | Tin |
| Material Resin | Nylon |
| Net Weight | 0.801/g |
| Number Of Rows | 1 |
| Orientation | Vertical |
| Pcb Locator | Yes |
| Pcb Retention | Yes |
| Pcb Thickness Recommended | 1.60mm |
| Pc Tail Length | 3.50mm |
| Pitch Mating Interface | 4.20mm |
| Pitch Termination Interface | 4.20mm |
| Plating Min Mating | 0.889µm |
| Plating Min Termination | 0.889µm |
| Polarized To Mating Part | Yes |
| Polarized To Pcb | Yes |
| Shrouded | Shrouded |
| Stackable | No |
| Temperature Range Operating | -40° to +105°C |
| Termination Interface Style | Through Hole |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| MINIFITJRHDR VT SR W/PGS TIN V | Heilind Americas |
| MINI-FIT JR HDR 03P VT 94V-2 | TTI Americas |
| Minifitjrhdr Vt Sr W/Pgs Tin V-2 3Ckt Rohs Compliant: Yes |Molex 39-30-1039 | Newark Electronics |
| CONN, HEADER, 3POS, 1ROW, 4.2MM | Farnell |
| MINI-FIT JR. HEADER 94V-2 | TTI Europe |
| 03P Mini-Fit JR Header W PEG 180° | Rutronik |
| CONNECTOR, HEADER, 3POS, 1ROW, 4.2MM | element14 |
| PCB Header 1-row 3-pole V-2 Snapin | Schukat Electronic |
| Molex 39301039 Mini-fit Jr. Header 3 Pin 4.2mm Pitch PCB Lock Tin | Rapid Electronics |
| Molex Einbau-Buchsenleiste (Standard) Polzahl Gesamt 3 Rastermaß: 4.2 mm 39301039 1 St. Tray | Conrad |
| Molex 39-30-1039 PCB Header | RS |
| Connector: wire-board | TME |
| CONN RECT/PCB HEADER 3 POS 1-ROW VERT W/PEG LOCK MINI-FIT JR NYLON TIN PLATE CNT | RS Americas |
| Conn Power Header 3 POS 4.2mm Solder ST Through Hole 3 Terminal 1 Port Tray | Avnet America |
Frequently Asked Questions
Where can I find additional details, specifications and documents for a 39301039?
Additional datasheets, footprints and schematics for 39301039 are listed on our Part Details page. You can also find images and similar parts to 39301039 on this page.
What pricing and inventory information can I view?
Distributor pricing and stock information is available for 39301039 on our Product Comparison page. Access via the 'View Pricing & Stock' button to view 39301039 price breaks, MOQs, lead times, inventory and SKUs from distributors.
What category does 39301039 fall under?
The 39301039 is listed under PCB Headers and Receptacles.
Can I view similar or alternative parts?
You can view similar parts to 39301039 when available in the PCB Headers and Receptacles range under the specifications section at the bottom of the details page.
Who can I contact for technical support of the product?
Submit any questions directly to the customer support team of the distributor listing the product. For the 39301039 you can contact the distributor directly for product support, shipping queries etc.
Is the 39301039 RoHS compliant?
Yes. This part has been flagged as RoHS Compliant by Molex.
Which authorised distributors for 39301039 have stock available?
Authorised distributors including Heilind Americas, TTI Americas, Newark Electronics, Farnell and TTI Europe have stock available or on a lead time for 39301039.
How do I check stock and lead times for all distributors?
Stock availability and lead times will be displayed for 39301039 often in real-time on the comparison pages.
What if I can't find stock of 39301039?
You can fill out our help required form which you can use to request a quote for 39301039 from some of our verified obsolescence suppliers. Alternatively, contact us via our web chat in the bottom left of your screen and one of our team will try to help.
