39532125 Easy-On by Molex
Easy-On FFC/FPC Connector, 1.25mm Pitch, Through-Hole, Vertical, ZIF, 12 Circuits
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
39-53-2125,
0039532125, 5597-12CPB7F |
Where to Buy
Prices starting from US$0.55
| Distributor | Stock | ||
|---|---|---|---|
|
Conrad
from US$1.10
|
20,829
in stock
|
Buy Now |
|
Farnell
from US$0.94
|
18,900
in stock
|
Buy Now |
|
Newark Electronics
from US$0.76
|
13,904
in stock
|
Buy Now |
|
TTI Europe
from US$0.65
|
180
in stock
|
Buy Now |
|
TME
from US$0.75
|
37
in stock
|
Buy Now |
|
RS
from US$0.87
|
19
in stock
|
Buy Now |
|
element14
from US$0.81
|
0
in stock
|
Buy Now |
|
Heilind Americas
from US$0.59
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.55
|
0
in stock
|
Buy Now |
|
|
TTI Asia
from US$0.61
|
0
in stock
|
Buy Now |
|
EME
from US$0.76
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | Easy-On |
|---|
Electrical |
|
|---|---|
| Current Maximum Per Contact | 1.0A |
| Voltage Maximum | 200V |
Physical |
|
|---|---|
| Actuator Type | Slider |
| Circuits Loaded | 12 |
| Color Resin | Natural |
| Contact Position | N/A |
| Durability Mating Cycles Max | 30 |
| Mated Height | 7.50mm |
| Material Metal | Phosphor Bronze |
| Material Plating Mating | Tin-Bismuth |
| Material Plating Termination | Tin-Bismuth |
| Material Resin | Polyester |
| Net Weight | 1145.140/mg |
| Orientation | Vertical |
| Pcb Locator | No |
| Pcb Mounting | Through Hole |
| Pcb Retention | No |
| Pc Tail Length | 3.50mm |
| Pitch Mating Interface | 1.25mm |
| Plating Min Mating | 1.016µm |
| Plating Min Termination | 1.016µm |
| Polarized To Pcb | No |
| Stackable | No |
| Temperature Range Operating | -20° to +80°C |
| Wire Cable Type | FFC/FPC |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| Molex FFC/FPC-Anschluss Polzahl Gesamt 12 Rastermaß: 1.25 mm 39532125 1 St. Tray | Conrad |
| FPC CONN, RCPT, 12POS, 1ROW, 1.25MM | Farnell |
| Ffc & Fpc Connectors 1.25 Mm Ffc/Fpc Rohs Compliant: Yes |Molex 39-53-2125 | Newark Electronics |
| 1.25 MM FFC/FPC CONNECTOR 12CK | TTI Europe |
| Connector: FFC/FPC | TME |
| Molex 39-53-2125 FPC Connector | RS |
| CONN, FFC/FPC, 12POS, 1ROW, 1.25MM | element14 |
| 1.25 FFC ZIF HSG ASSY 12CKT | Heilind Americas |
| 1.25MM REC 12P RA TOP TH | TTI Asia |
