428205212 Mini-Fit Sr. by Molex
Mini-Fit Sr. Right-Angle Header, 10.00mm Pitch, Single Row, 5 Circuits, 3.50mm Tail Length, for 1.57mm PCB, Tin (Sn) Plating, with Clip, USE NYE LUBE ON MATING SURFACES
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
42820-5212,
0428205212 |
Where to Buy
Prices starting from US$8.49
| Distributor | Stock | ||
|---|---|---|---|
|
Newark Electronics
from US$10.26
|
250
in stock
|
Buy Now |
|
Avnet America
from US$8.49
|
250
in stock
|
Buy Now |
|
TME
from US$12.18
|
100
in stock
|
Buy Now |
|
Farnell
from US$12.46
|
90
in stock
|
Buy Now |
|
RS Americas
from US$14.28
|
0
in stock
|
Buy Now |
|
TTI Europe
from US$11.06
|
0
in stock
|
Buy Now |
|
Sager
from US$9.90
|
0
in stock
|
Buy Now |
|
Heilind Americas
from US$9.74
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$9.32
|
0
in stock
|
Buy Now |
|
|
TTI Asia
from US$11.00
|
0
in stock
|
Buy Now |
|
Avnet Abacus
-
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | Mini-Fit Sr. |
|---|---|
| Application | Wire-to-Board |
Electrical |
|
|---|---|
| Current Maximum Per Contact | 50.0A |
| Voltage Maximum | 600V AC (RMS)/DC |
Physical |
|
|---|---|
| Breakaway | No |
| Circuits Loaded | 5 |
| Circuits Maximum | 5 |
| Color Resin | Black |
| Durability Mating Cycles Max | 30 |
| First Mate Last Break | No |
| Flammability | 94V-0 |
| Glow Wire Capable | No |
| Guide To Mating Part | No |
| Keying To Mating Part | No |
| Lock To Mating Part | Yes |
| Material Metal | Copper Alloy |
| Material Plating Mating | Tin |
| Material Plating Termination | Tin |
| Material Resin | Nylon |
| Net Weight | 15.233/g |
| Number Of Rows | 1 |
| Orientation | Right Angle |
| Pcb Locator | No |
| Pcb Retention | Yes |
| Pcb Thickness Recommended | 1.57mm |
| Pc Tail Length | 3.50mm |
| Pitch Mating Interface | 10.00mm |
| Pitch Termination Interface | 10.00mm |
| Plating Min Mating | 2.540µm |
| Plating Min Termination | 2.540µm |
| Polarized To Mating Part | Yes |
| Polarized To Pcb | Yes |
| Shrouded | Shrouded |
| Stackable | No |
| Temperature Range Operating | -40° to +105°C |
| Termination Interface Style | Through Hole |
