5023820471 CLIK-Mate by Molex
1.25mm Pitch CLIK-Mate Wire-to-Board PCB Receptacle, Single Row, Vertical, Gold Plating, 4 Circuits
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: | 502382-0471 |
Where to Buy
Prices starting from US$0.26
| Distributor | Stock | ||
|---|---|---|---|
|
Newark Electronics
from US$0.76
|
0
in stock
|
Buy Now |
|
element14
from US$0.63
|
0
in stock
|
Buy Now |
|
TTI Europe
from US$0.51
|
0
in stock
|
Buy Now |
|
Sager
from US$0.55
|
0
in stock
|
Buy Now |
|
Heilind Americas
from US$0.54
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.35
|
0
in stock
|
Buy Now |
|
Farnell
from US$0.26
|
0
in stock
|
Buy Now |
|
Avnet Asia
-
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | CLIK-Mate |
|---|---|
| Application | Wire-to-Board |
Electrical |
|
|---|---|
| Current Maximum Per Contact | 1.0A |
| Voltage Maximum | 50V AC (RMS)/DC |
Physical |
|
|---|---|
| Circuits Loaded | 4 |
| Circuits Maximum | 4 |
| Color Resin | Natural |
| Durability Mating Cycles Max | 30 |
| First Mate Last Break | No |
| Glow Wire Capable | No |
| Guide To Mating Part | Yes |
| Keying To Mating Part | Yes |
| Lock To Mating Part | Yes |
| Mated Height | 7.80mm |
| Material Metal | Copper Alloy |
| Material Plating Mating | Gold |
| Material Plating Termination | Gold |
| Material Resin | High Temperature Thermoplastic |
| Net Weight | 240.969/mg |
| Number Of Rows | 1 |
| Orientation | Vertical |
| Pcb Locator | No |
| Pcb Retention | Yes |
| Pitch Mating Interface | 1.25mm |
| Pitch Termination Interface | 1.25mm |
| Plating Min Mating | 0.102µm |
| Plating Min Termination | 0.102µm |
| Polarized To Mating Part | Yes |
| Polarized To Pcb | No |
| Stackable | No |
| Temperature Range Operating | -40° to +105°C |
| Termination Interface Style | Surface Mount |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| Connector, Rcpt, 4Pos, 1Row, 1.25Mm | Newark Electronics |
| CONNECTOR, RCPT, 4POS, 1ROW, 1.25MM | element14 |
| 1.25 W/B SGL S/T ASSY | TTI Europe |
| Headers & Wire Housings 1.25 W/B Sgl S/T Assy 4CktEmbsTpPkg | Sager |
| 1.25 W/B SGL S/T ASSY 4CK TPPKG | Heilind Americas |
| 1.25 W/B SGL S/T ASSY 4CKTEMBSTPPKG | Farnell |
| Connector, PCB Receptacle, Straight, 4 Position, 1 Row, Solder, Surface Mount | Avnet Asia |
