5031590800 CLIK-Mate by Molex
1.50mm Pitch, CLIK-Mate PCB Receptacle, Single Row, Through Hole, Vertical, Tin Plating, Positive Lock, with Peg, 8 Circuits, Natural
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: | 503159-0800 |
Where to Buy
Prices starting from US$0.29
| Distributor | Stock | ||
|---|---|---|---|
|
Conrad
from US$0.39
|
20,079
in stock
|
Buy Now |
|
Farnell
from US$0.46
|
18,090
in stock
|
Buy Now |
|
Newark Electronics
from US$0.47
|
8,135
in stock
|
Buy Now |
|
element14
from US$0.47
|
836
in stock
|
Buy Now |
|
RS
from US$0.66
|
0
in stock
|
Buy Now |
|
Avnet America
from US$0.33
|
0
in stock
|
Buy Now |
|
TME
from US$0.41
|
0
in stock
|
Buy Now |
|
|
RS Americas
from US$0.54
|
0
in stock
|
Buy Now |
|
Sager
from US$0.31
|
0
in stock
|
Buy Now |
|
Heilind Americas
from US$0.35
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.29
|
0
in stock
|
Buy Now |
|
TTI Asia
from US$0.30
|
0
in stock
|
Buy Now |
|
Avnet Abacus
-
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | CLIK-Mate |
|---|---|
| Application | Wire-to-Board |
Electrical |
|
|---|---|
| Current Maximum Per Contact | 2.0A |
| Voltage Maximum | 100V |
Physical |
|
|---|---|
| Circuits Loaded | 8 |
| Circuits Maximum | 8 |
| Color Resin | Beige |
| Durability Mating Cycles Max | 30 |
| First Mate Last Break | No |
| Gender | Female |
| Glow Wire Capable | No |
| Guide To Mating Part | No |
| Keying To Mating Part | No |
| Lock To Mating Part | Yes |
| Material Metal | Copper Alloy |
| Material Plating Mating | Tin |
| Material Plating Termination | Tin |
| Mounting Style | Through Hole |
| Net Weight | 681.601/mg |
| Number Of Rows | 1 |
| Orientation | Vertical |
| Pcb Locator | Yes |
| Pcb Retention | Yes |
| Pitch Mating Interface | 1.50mm |
| Pitch Termination Interface | 1.50mm |
| Plating Min Mating | 1.000µm |
| Plating Min Termination | 1.000µm |
| Polarized To Mating Part | Yes |
| Polarized To Pcb | Yes |
| Stackable | No |
| Temperature Range Operating | -40° to +105°C |
| Termination Interface Style | Through Hole |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| Molex Einbau-Buchsenleiste (Standard) 503159-0800 1 St. Tray | Conrad |
| PCB RECEPTACLES | Farnell |
| Wtb Conn, Rcpt, 8Pos, 1Row, 1.5Mm | Newark Electronics |
| WTB CONN, RCPT, 8POS, 1ROW, 1.5MM | element14 |
| Molex 503159-0800 Receptacle | RS |
| Conn Wire to Board RCP 8 POS 3mm Solder ST Thru-Hole Tray | Avnet America |
| Connector: wire-board | TME |
| 1.5W/BSGLDIPSTRECASSY8CKTW/BOSWKNKBEIGE | RS Americas |
| Headers & Wire Housings 1.5W/BSGLDIPSTRecAssy8CktW/BosWKnkBeige | Sager |
| 1.5W/BSGLDIPSTRECASSY8CKTW/BO WKNKBEIGE | Heilind Americas |
| 1.5W/BSGLDIPSTRECASSY8CKT | TTI Asia |
Frequently Asked Questions
Where can I find additional details, specifications and documents for a 5031590800?
Additional datasheets, footprints and schematics for 5031590800 are listed on our Part Details page. You can also find images and similar parts to 5031590800 on this page.
What pricing and inventory information can I view?
Distributor pricing and stock information is available for 5031590800 on our Product Comparison page. Access via the 'View Pricing & Stock' button to view 5031590800 price breaks, MOQs, lead times, inventory and SKUs from distributors.
What category does 5031590800 fall under?
The 5031590800 is listed under PCB Headers and Receptacles.
Can I view similar or alternative parts?
You can view similar parts to 5031590800 when available in the PCB Headers and Receptacles range under the specifications section at the bottom of the details page.
Who can I contact for technical support of the product?
Submit any questions directly to the customer support team of the distributor listing the product. For the 5031590800 you can contact the distributor directly for product support, shipping queries etc.
Is the 5031590800 RoHS compliant?
Yes. This part has been flagged as RoHS Compliant by Molex.
Which authorised distributors for 5031590800 have stock available?
Authorised distributors including Conrad, Farnell, Newark Electronics, element14 and RS have stock available or on a lead time for 5031590800.
How do I check stock and lead times for all distributors?
Stock availability and lead times will be displayed for 5031590800 often in real-time on the comparison pages.
What if I can't find stock of 5031590800?
You can fill out our help required form which you can use to request a quote for 5031590800 from some of our verified obsolescence suppliers. Alternatively, contact us via our web chat in the bottom left of your screen and one of our team will try to help.
