524653271 SlimStack by Molex
SlimStack Board-to-Board Connector, 0.80mm Pitch, Rigid Type Receptacle, 4.50 or 5.65mm Mated Height, Vertical, 32 Circuits, without Boss
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
52465-3271,
0524653271 |
Where to Buy
Prices starting from US$0.66
| Distributor | Stock | ||
|---|---|---|---|
|
Newark Electronics
from US$1.71
|
1,000
in stock
|
Buy Now |
|
Farnell
from US$2.13
|
1,000
in stock
|
Buy Now |
|
RS
from US$1.75
|
0
in stock
|
Buy Now |
|
Avnet America
from US$1.80
|
0
in stock
|
Buy Now |
|
|
RS Americas
from US$1.89
|
0
in stock
|
Buy Now |
|
element14
from US$0.66
|
0
in stock
|
Buy Now |
|
Heilind Americas
from US$1.64
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$1.16
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | SlimStack |
|---|---|
| Application | Board-to-Board |
Electrical |
|
|---|---|
| Current Maximum Per Contact | 0.5A |
| Voltage Maximum | 50V |
Physical |
|
|---|---|
| Circuits Loaded | 32 |
| Circuits Maximum | 32 |
| Color Resin | Natural |
| Durability Mating Cycles Max | 30 |
| Glow Wire Capable | No |
| Keying To Mating Part | Yes |
| Lock To Mating Part | No |
| Mated Height | 4.50mm, 5.65mm |
| Mated Width | 4.70mm, 5.10mm |
| Material Metal | Phosphor Bronze |
| Material Plating Mating | Tin |
| Material Plating Termination | Tin |
| Material Resin | High Temperature Thermoplastic |
| Net Weight | 329.285/mg |
| Number Of Rows | 2 |
| Orientation | Vertical |
| Pcb Locator | No |
| Pcb Retention | No |
| Pcb Thickness Recommended | 1.60mm |
| Pitch Mating Interface | 0.80mm |
| Plating Min Mating | 1.016µm |
| Plating Min Termination | 1.016µm |
| Polarized To Pcb | No |
| Temperature Range Operating | -40° to +105°C |
| Termination Interface Style | Surface Mount |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| Board-To-Board Connector, 52465 Series, Surface Mount, Receptacle, 32, 0.8 Mm, Tin Plated Contacts |Molex 52465-3271 | Newark Electronics |
| MEZZANINE CONN, RCPT, 32POS, 2ROW, 0.8MM | Farnell |
| Molex 52465-3271 PCB Header | RS |
| Conn Board to Board RCP 32 POS 0.8mm Solder ST SMD Embossed T/R | Avnet America |
| 0.8 BTB HSG ASSY SMT 32CKT EMBSTP PKG | RS Americas |
| CONNECTOR, RCPT, 32POS, 2ROW, 0.8MM | element14 |
| 0.8 BTB HSG ASSY SMT 32CKT EM STP PKG | Heilind Americas |
Frequently Asked Questions
Where can I find additional details, specifications and documents for a 524653271?
Additional datasheets, footprints and schematics for 524653271 are listed on our Part Details page. You can also find images and similar parts to 524653271 on this page.
What pricing and inventory information can I view?
Distributor pricing and stock information is available for 524653271 on our Product Comparison page. Access via the 'View Pricing & Stock' button to view 524653271 price breaks, MOQs, lead times, inventory and SKUs from distributors.
What category does 524653271 fall under?
The 524653271 is listed under Board-to-Board Connectors.
Can I view similar or alternative parts?
You can view similar parts to 524653271 when available in the Board-to-Board Connectors range under the specifications section at the bottom of the details page.
Who can I contact for technical support of the product?
Submit any questions directly to the customer support team of the distributor listing the product. For the 524653271 you can contact the distributor directly for product support, shipping queries etc.
Is the 524653271 RoHS compliant?
Yes. This part has been flagged as RoHS Compliant by Molex.
Which authorised distributors for 524653271 have stock available?
Authorised distributors including Newark Electronics, Farnell, RS, Avnet America and RS Americas have stock available or on a lead time for 524653271.
How do I check stock and lead times for all distributors?
Stock availability and lead times will be displayed for 524653271 often in real-time on the comparison pages.
What if I can't find stock of 524653271?
You can fill out our help required form which you can use to request a quote for 524653271 from some of our verified obsolescence suppliers. Alternatively, contact us via our web chat in the bottom left of your screen and one of our team will try to help.
