528060510 Easy-On by Molex
1.00mm Pitch Easy-On FFC/FPC Connector, Vertical, Surface Mount Compatible, Non-ZIF, Kinked PC Tails, 5 Circuits
| Status: | Not Recommended For New Design |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
52806-0510,
0528060510 |
Where to Buy
Prices starting from US$0.0170
| Distributor | Stock | ||
|---|---|---|---|
|
TME
from US$0.12
|
85,387
in stock
|
Buy Now |
|
Conrad
from US$0.27
|
85,387
in stock
|
Buy Now |
|
Farnell
from US$0.21
|
76,849
in stock
|
Buy Now |
|
TTI Asia
from US$0.12
|
16,000
in stock
|
Buy Now |
|
element14
from US$0.18
|
7,909
in stock
|
Buy Now |
|
Newark Electronics
from US$0.0170
|
513
in stock
|
Buy Now |
|
RS
from US$0.18
|
0
in stock
|
Buy Now |
|
Avnet America
from US$0.10
|
0
in stock
|
Buy Now |
|
|
RS Americas
from US$0.15
|
0
in stock
|
Buy Now |
|
Sager
from US$0.13
|
0
in stock
|
Buy Now |
|
Heilind Americas
from US$0.13
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.11
|
0
in stock
|
Buy Now |
|
Avnet Abacus
-
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | Easy-On |
|---|
Electrical |
|
|---|---|
| Current Maximum Per Contact | 0.5A |
| Voltage Maximum | 50V |
Physical |
|
|---|---|
| Actuator Type | Non-ZIF |
| Circuits Loaded | 5 |
| Color Resin | Natural |
| Contact Position | N/A |
| Durability Mating Cycles Max | 10 |
| Mated Height | 5.40mm |
| Material Metal | Phosphor Bronze |
| Material Plating Mating | Tin |
| Material Plating Termination | Tin |
| Material Resin | High Temperature Thermoplastic |
| Net Weight | 186.601/mg |
| Orientation | Vertical |
| Pcb Locator | No |
| Pcb Mounting | Through Hole - Kinked Pin |
| Pcb Retention | No |
| Pcb Thickness Recommended | 1.60mm |
| Pc Tail Length | 3.20mm |
| Pitch Mating Interface | 1.00mm |
| Pitch Termination Interface | 1.00mm |
| Plating Min Mating | 0.914µm |
| Plating Min Termination | 0.914µm |
| Polarized To Pcb | No |
| Stackable | No |
| Temperature Range Operating | -20° to +80°C |
| Wire Cable Type | FFC/FPC |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| Connector: FFC/FPC | TME |
| Molex Buchsenleiste (Standard) Polzahl Gesamt 5 Rastermaß: 1.00 mm 528060510 1 St. Tray | Conrad |
| FPC CONN, RCPT, 5POS, 1ROW, 1MM | Farnell |
| 1.0 FFC NON ZIF DIP HSG | TTI Asia |
| CONNECTOR, FFC/FPC, 5POS, 1ROW, 1MM | element14 |
| 1.0 Ffc Non Zif Dip Hsg Assy 5Ckt Rohs Compliant: Yes |Molex 52806-0510 | Newark Electronics |
| Molex 52806-0510 FPC Connector | RS |
| Conn FFC Connector SKT 5 POS 2mm Solder ST Thru-Hole Tray | Avnet America |
| 1.0 FFC NON ZIF DIP HSG ASSY 5CKT | RS Americas |
| FFC & FPC Connectors 1.0 FFC Non ZIF DIP Hsg Assy 5Ckt | Sager |
| 1.0 FFC NON ZIF DIP HSG ASSY CKT | Heilind Americas |
Frequently Asked Questions
Where can I find additional details, specifications and documents for a 528060510?
Additional datasheets, footprints and schematics for 528060510 are listed on our Part Details page. You can also find images and similar parts to 528060510 on this page.
What pricing and inventory information can I view?
Distributor pricing and stock information is available for 528060510 on our Product Comparison page. Access via the 'View Pricing & Stock' button to view 528060510 price breaks, MOQs, lead times, inventory and SKUs from distributors.
What category does 528060510 fall under?
The 528060510 is listed under FFC / FPC Connectors.
Can I view similar or alternative parts?
You can view similar parts to 528060510 when available in the FFC / FPC Connectors range under the specifications section at the bottom of the details page.
Who can I contact for technical support of the product?
Submit any questions directly to the customer support team of the distributor listing the product. For the 528060510 you can contact the distributor directly for product support, shipping queries etc.
Is the 528060510 RoHS compliant?
Yes. This part has been flagged as RoHS Compliant by Molex.
Which authorised distributors for 528060510 have stock available?
Authorised distributors including TME, Conrad, Farnell, TTI Asia and element14 have stock available or on a lead time for 528060510.
How do I check stock and lead times for all distributors?
Stock availability and lead times will be displayed for 528060510 often in real-time on the comparison pages.
What if I can't find stock of 528060510?
You can fill out our help required form which you can use to request a quote for 528060510 from some of our verified obsolescence suppliers. Alternatively, contact us via our web chat in the bottom left of your screen and one of our team will try to help.
