528081271 Easy-On by Molex
Easy-On FFC/FPC Connector, 1.00mm Pitch, Surface Mount, Vertical, Non-ZIF, Tin (Sn) Plating, with Pick-and-Place Polyimide Tape, 12 Circuits
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
52808-1271,
0528081271 |
Where to Buy
Prices starting from US$0.16
| Distributor | Stock | ||
|---|---|---|---|
|
CoreStaff
from US$0.16
|
1,171
in stock
|
Buy Now |
|
RS
from US$0.46
|
20
in stock
|
Buy Now |
|
Newark Electronics
from US$0.42
|
0
in stock
|
Buy Now |
|
Avnet America
from US$0.27
|
0
in stock
|
Buy Now |
|
|
RS Americas
from US$0.58
|
0
in stock
|
Buy Now |
|
Conrad
from US$0.68
|
0
in stock
|
Buy Now |
|
TTI Americas
from US$0.35
|
0
in stock
|
Buy Now |
|
Sager
from US$0.33
|
0
in stock
|
Buy Now |
|
Heilind Americas
from US$0.34
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.27
|
0
in stock
|
Buy Now |
|
Farnell
from US$0.41
|
0
in stock
|
Buy Now |
|
|
TTI Asia
from US$0.31
|
0
in stock
|
Buy Now |
|
|
Avnet Asia
-
|
0
in stock
|
Buy Now |
|
Avnet Abacus
-
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | Easy-On |
|---|
Electrical |
|
|---|---|
| Current Maximum Per Contact | 0.5A |
| Voltage Maximum | 125V |
Physical |
|
|---|---|
| Actuator Type | Non-ZIF |
| Circuits Loaded | 12 |
| Color Resin | Natural |
| Contact Position | N/A |
| Durability Mating Cycles Max | 10 |
| Mated Height | 5.05mm |
| Material Metal | Phosphor Bronze |
| Material Plating Mating | Tin-Bismuth |
| Material Plating Termination | Tin-Bismuth |
| Material Resin | High Temperature Thermoplastic |
| Net Weight | 333.500/mg |
| Orientation | Vertical |
| Pcb Locator | No |
| Pcb Mounting | Surface Mount |
| Pcb Retention | No |
| Pitch Mating Interface | 1.00mm |
| Pitch Termination Interface | 1.00mm |
| Polarized To Pcb | No |
| Stackable | No |
| Temperature Range Operating | -20° to +80°C |
| Wire Cable Type | FFC/FPC |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| Molex 52808-1271 FPC Connector | RS |
| Connector, Ffc/Fpc, 12Pos, 1Row, 1Mm | Newark Electronics |
| FFC/FPC SMT SERIES 1MM PITCH 12 WAY STRAIGHT SMT FEMALE FPC CONN, CONTACT | RS Americas |
| Molex Buchsenleiste (Standard) Polzahl Gesamt 12 Rastermaß: 1 mm 528081271 1 St. Tape on Full reel | Conrad |
| 1.00MM REC 12P VT SMT | TTI Americas |
| FFC & FPC Connectors 1.00MM REC 12P VT SMT | Sager |
| 1.0 FFC NON ZIFHSGASSY12CKTW/ PEMBSTPPKG | Heilind Americas |
| CONN, FFC/FPC, 12POS, 1ROW, 1MM | Farnell |
