532611271 PicoBlade by Molex
1.25mm Pitch, PicoBlade PCB Header, Single Row, Right-Angle, Surface Mount, Tin (Sn) Plating, Friction Lock, 12 Circuits, Natural, Tape and Reel
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
53261-1271,
0532611271 |
Where to Buy
Prices starting from US$0.25
| Distributor | Stock | ||
|---|---|---|---|
|
Farnell
from US$0.75
|
36,000
in stock
|
Buy Now |
|
Newark Electronics
from US$0.77
|
10,904
in stock
|
Buy Now |
|
element14
from US$0.83
|
10,904
in stock
|
Buy Now |
|
CoreStaff
from US$0.47
|
6,380
in stock
|
Buy Now |
|
RS
from US$0.55
|
4,214
in stock
|
Buy Now |
|
TTI Americas
from US$0.57
|
3,200
in stock
|
Buy Now |
|
Heilind Americas
from US$0.55
|
2,250
in stock
|
Buy Now |
|
Rapid Electronics
from US$0.95
|
699
in stock
|
Buy Now |
|
Conrad
from US$0.58
|
699
in stock
|
Buy Now |
|
Kruse
-
|
1,640
in stock
|
Buy Now |
|
Offical Electronic
-
|
84
in stock
|
Buy Now |
|
Rutronik
from US$0.53
|
0
in stock
|
Buy Now |
|
Avnet America
from US$0.56
|
0
in stock
|
Buy Now |
|
TME
from US$0.54
|
0
in stock
|
Buy Now |
|
|
RS Americas
from US$0.95
|
0
in stock
|
Buy Now |
|
Compona
from US$0.45
|
0
in stock
|
Buy Now |
|
|
TTI Europe
from US$0.58
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.40
|
0
in stock
|
Buy Now |
|
|
TTI Asia
from US$0.25
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | PicoBlade |
|---|---|
| Application | Wire-to-Board |
Electrical |
|
|---|---|
| Current Maximum Per Contact | 1.0A |
| Voltage Maximum | 125V |
Physical |
|
|---|---|
| Breakaway | No |
| Circuits Loaded | 12 |
| Circuits Maximum | 12 |
| Color Resin | Natural |
| Durability Mating Cycles Max | 30 |
| First Mate Last Break | No |
| Flammability | 94V-0 |
| Gender | Male |
| Glow Wire Capable | No |
| Guide To Mating Part | Yes |
| Keying To Mating Part | No |
| Lock To Mating Part | Yes |
| Mated Height | 3.40mm |
| Material Metal | Phosphor Bronze |
| Material Plating Mating | Tin |
| Material Plating Termination | Tin |
| Material Resin | Polyamide (PA) |
| Net Weight | 319.200/mg |
| Number Of Rows | 1 |
| Orientation | Right Angle |
| Pcb Locator | No |
| Pcb Retention | Yes |
| Pitch Mating Interface | 1.25mm |
| Pitch Termination Interface | 1.25mm |
| Plating Min Mating | 1.016µm |
| Plating Min Termination | 1.016µm |
| Polarized To Pcb | Yes |
| Shrouded | Shrouded |
| Stackable | No |
| Temperature Range Operating | -40° to +105°C |
| Termination Interface Style | Surface Mount |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| CONN, R/A HEADER, 12POS, 1ROW, 1.25MM | Farnell |
| Connector, Header, 12Pos, 1Row, 1.25Mm | Newark Electronics |
| CONNECTOR, HEADER, 12POS, 1ROW, 1.25MM | element14 |
| Molex 53261-1271 PCB Header | RS |
| 1.25MM HDR 12P RA SMT | TTI Americas |
| 12CKT EMBOSS TAPE PACK FR 532 1-**10 | Heilind Americas |
| Molex 532611271 Picoblade PCB Header 12 Pins 1.25mm Pitch Smt | Rapid Electronics |
| Molex Einbau-Stiftleiste (Standard) Polzahl Gesamt 12 Rastermaß: 1.25 mm 532611271 1 St. Tape on Full reel | Conrad |
| STECKER RETT 12P M 90? SMD P.1 25 | Kruse |
| 12P HEADER RIGHT ANGLE SMT | Rutronik |
| Pin Header, Signal, 1.25 mm, 1 Rows, 12 Contacts, Surface Mount Right Angle, PicoBlade 53261 | Avnet America |
| Connector: wire-board | TME |
| CONN. | RS Americas |
| MOLEX 53261-1271 Plug Square 12p SMT 90° | Compona |
| 1.25 MM WIRE-TO-BOARD HEADER | TTI Europe |
