701075038 SL by Molex
SL Wire-to-Wire Panel Mount Crimp Housing, Single Row, Panel Mount Plug with TPA Feature, 4 Circuits, Black
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
70107-5038,
0701075038 |
Where to Buy
Prices starting from US$0.22
Specifications
| Product Name | SL |
|---|---|
| Application | Wire-to-Wire |
Physical |
|
|---|---|
| Circuits Maximum | 4 |
| Color Resin | Black |
| Flammability | 94V-0 |
| Gender | Plug |
| Glow Wire Capable | No |
| Lock To Mating Part | Yes |
| Material Resin | Polyester |
| Net Weight | 1.320/g |
| Number Of Rows | 1 |
| Panel Mount | Yes |
| Pitch Mating Interface | 2.54mm |
| Polarized To Mating Part | Yes |
| Stackable | No |
| Temperature Range Operating | -40° to +105°C |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| Molex Stiftgehäuse-Kabel 701075038 1 St. | Conrad |
| CONNECTOR HOUSING, PLUG, 4POS, 2.54MM | Farnell |
| SL WTW CONN SR W/MTGE OPT F 4CKT LATCH | Heilind Americas |
| Connector Housing, Plug, 4Pos | Newark Electronics |
| Molex 70107-5038 Crimp Housing | RS |
