855075001 Modular Jack 8/8,RJ45 by Molex
Modular Jack, Cat5e, Vertical, Top Entry, Through Hole, 8/8, Int. Shielded, with Ribs, Tray
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
85507-5001,
0855075001 |
Where to Buy
Prices starting from US$2.23
| Distributor | Stock | ||
|---|---|---|---|
|
TTI Americas
from US$3.07
|
4,592
in stock
|
Buy Now |
|
|
TTI Europe
from US$3.22
|
2,352
in stock
|
Buy Now |
|
Newark Electronics
from US$3.80
|
2,240
in stock
|
Buy Now |
|
Avnet America
from US$2.34
|
2,240
in stock
|
Buy Now |
|
Heilind Americas
from US$2.42
|
480
in stock
|
Buy Now |
|
element14
from US$3.53
|
386
in stock
|
Buy Now |
|
Farnell
from US$3.69
|
381
in stock
|
Buy Now |
|
TME
from US$2.92
|
112
in stock
|
Buy Now |
|
Avnet Abacus
-
|
6,160
in stock
|
Buy Now |
|
Offical Electronic
-
|
38
in stock
|
Buy Now |
|
RS
from US$4.68
|
0
in stock
|
Buy Now |
|
|
RS Americas
from US$4.02
|
0
in stock
|
Buy Now |
|
Sager
from US$2.99
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$2.23
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | Modular Jack 8/8,RJ45 |
|---|
Electrical |
|
|---|---|
| Current Maximum Per Contact | 1.5A |
| Shielded | Yes |
| Voltage Maximum | 125V DC |
Physical |
|
|---|---|
| Boot Color | N/A |
| Color Resin | Black |
| Durability Mating Cycles Max | 2500 |
| Flammability | 94V-0 |
| Inverted Top Latch | No |
| Jack Height | 16.25mm |
| Light Pipes Leds | None |
| Material Metal | Phosphor Bronze |
| Material Plating Mating | Gold over Palladium Nickel |
| Material Plating Termination | Tin |
| Material Resin | High Temperature Thermoplastic |
| Net Weight | 3.300/g |
| Orientation | Vertical (Top Entry) |
| Pcb Locator | Yes |
| Pcb Retention | Yes |
| Pcb Thickness Recommended | 1.57mm |
| Pitch Mating Interface | 1.02mm |
| Pitch Termination Interface | 1.27mm |
| Plating Min Mating | 0.051µm, 1.016µm |
| Plating Min Termination | 1.905µm |
| Port Configuration | 1x1 |
| Positions Loaded Contacts | 8/8 |
| Temperature Range Operating | -40° to +85°C |
| Termination Interface Style | Through Hole |
| Waterproof Dustproof | No |
| Wire Cable Type | N/A |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| MDJCK 8/8 VT SHLD CAT 5 | TTI Americas |
| 8/8 MOD JACK VERTICAL STD PRO | TTI Europe |
| Cat5E Te Th In.shield Cat5 Jack 8/8 Rohs Compliant: Yes |Molex 85507-5001 | Newark Electronics |
| Modular Connector, RJ45 Jack, 1 x 1 (Port), 8P8C, Cat5e, Through Hole Mount | Avnet America |
| TE TH IN.SHIELD CAT5 JACK 8/8 | Heilind Americas |
| CONN, RJ45, JACK, 1PORT, 8P8C, CAT5E | element14 |
| Connector: RJ45 | TME |
| Molex 85507-5001 RJ45 Connector | RS |
| Modular Connectors / Ethernet Connectors MDJCK 8/8 VT SHLD CAT 5 | Sager |
