855105019 Modular Jack 6/6 by Molex
Modular Jack, Vertical, Top Entry, Surface Mount, 6/6, Solder Tabs, 13" Reel
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
85510-5019,
0855105019 |
Where to Buy
Prices starting from US$0.99
| Distributor | Stock | ||
|---|---|---|---|
|
Farnell
from US$1.68
|
7,863
in stock
|
Buy Now |
|
TTI Europe
from US$0.99
|
1,224
in stock
|
Buy Now |
|
Newark Electronics
from US$2.28
|
1,109
in stock
|
Buy Now |
|
element14
from US$1.90
|
1,109
in stock
|
Buy Now |
|
RS
from US$1.26
|
26
in stock
|
Buy Now |
|
TME
from US$1.20
|
0
in stock
|
Buy Now |
|
|
TTI Asia
from US$1.31
|
0
in stock
|
Buy Now |
|
Offical Electronic
-
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | Modular Jack 6/6 |
|---|
Electrical |
|
|---|---|
| Current Maximum Per Contact | 1.5A |
| Shielded | No |
| Voltage Maximum | 125V DC |
Physical |
|
|---|---|
| Boot Color | N/A |
| Color Resin | Black |
| Durability Mating Cycles Max | 2500 |
| Flammability | 94V-0 |
| Inverted Top Latch | No |
| Jack Height | 15.70mm |
| Light Pipes Leds | None |
| Material Metal | Copper Alloy |
| Material Plating Mating | Gold over Palladium Nickel |
| Material Plating Termination | Tin |
| Material Resin | High Temperature Thermoplastic |
| Net Weight | 2.416/g |
| Orientation | Vertical (Top Entry) |
| Pcb Locator | No |
| Pcb Retention | Yes |
| Pitch Mating Interface | 1.02mm |
| Pitch Termination Interface | 1.27mm |
| Plating Min Mating | 0.051µm, 1.016µm |
| Plating Min Termination | 1.905µm |
| Port Configuration | 1x1 |
| Positions Loaded Contacts | 6/6 |
| Temperature Range Operating | -40° to +85°C |
| Termination Interface Style | Surface Mount |
| Waterproof Dustproof | No |
| Wire Cable Type | N/A |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| MODULAR AND ETHERNET CONNECTORS | Farnell |
| 6/6 MOD JACK VERTICAL STD PRO | TTI Europe |
| Jack, Rj11, Vertical, 6/6 | Newark Electronics |
| JACK, RJ11, VERTICAL, 6/6 | element14 |
| Molex 85510-5019 RJ11 Connector | RS |
| Connector: RJ11 | TME |
| MDJCK 6/6 VT SMT | TTI Asia |
