874380443 Pico-SPOX by Molex
1.50mm Pitch, Pico-SPOX PCB Header, Single Row, Right-Angle, Surface Mount, Tin over Nickel Plating, Friction Lock, 4 Circuits, Tape and Reel, Beige
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
87438-0443,
0874380443 |
Where to Buy
Prices starting from US$0.20
| Distributor | Stock | ||
|---|---|---|---|
|
TTI Americas
from US$0.42
|
84,000
in stock
|
Buy Now |
|
Farnell
from US$0.47
|
49,000
in stock
|
Buy Now |
|
RS
from US$0.46
|
16,733
in stock
|
Buy Now |
|
|
TTI Europe
from US$0.34
|
7,000
in stock
|
Buy Now |
|
Newark Electronics
from US$0.41
|
3,285
in stock
|
Buy Now |
|
TME
from US$0.33
|
2,399
in stock
|
Buy Now |
|
Conrad
from US$0.27
|
945
in stock
|
Buy Now |
|
Heilind Americas
from US$0.63
|
31
in stock
|
Buy Now |
|
|
RS Americas
from US$0.20
|
10
in stock
|
Buy Now |
|
Avnet Abacus
-
|
88,000
in stock
|
Buy Now |
|
Tongyida Electronic
-
|
40,000
in stock
|
Buy Now |
|
Offical Electronic
-
|
32,000
in stock
|
Buy Now |
|
Rutronik
from US$0.29
|
0
in stock
|
Buy Now |
|
Avnet America
from US$0.27
|
0
in stock
|
Buy Now |
|
Compona
from US$0.22
|
0
in stock
|
Buy Now |
|
Sager
from US$0.33
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.25
|
0
in stock
|
Buy Now |
|
|
TTI Asia
from US$0.24
|
0
in stock
|
Buy Now |
|
|
Avnet Asia
-
|
0
in stock
|
Buy Now |
|
Walker Component Group
-
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | Pico-SPOX |
|---|---|
| Application | Wire-to-Board |
Electrical |
|
|---|---|
| Current Maximum Per Contact | 2.5A |
| Voltage Maximum | 250V |
Physical |
|
|---|---|
| Breakaway | No |
| Circuits Loaded | 4 |
| Circuits Maximum | 4 |
| Color Resin | Beige |
| Durability Mating Cycles Max | 10 |
| First Mate Last Break | No |
| Flammability | 94V-0 |
| Glow Wire Capable | No |
| Guide To Mating Part | No |
| Keying To Mating Part | Yes |
| Lock To Mating Part | Yes |
| Material Metal | Brass |
| Material Plating Mating | Tin |
| Material Plating Termination | Tin |
| Material Resin | High Temperature Thermoplastic |
| Net Weight | 229.000/mg |
| Number Of Rows | 1 |
| Orientation | Right Angle |
| Pcb Locator | No |
| Pcb Retention | No |
| Pitch Mating Interface | 1.50mm |
| Plating Min Mating | 2.540µm |
| Plating Min Termination | 2.540µm |
| Polarized To Mating Part | Yes |
| Polarized To Pcb | No |
| Shrouded | Shrouded |
| Stackable | No |
| Temperature Range Operating | -55° to +105°C |
| Termination Interface Style | Surface Mount |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| 1.50MM HDR 04P RA SMT SHROUD | TTI Americas |
| PIN HEADERS | Farnell |
| Molex 87438-0443 PCB Header | RS |
| 1.50 MM WIRE-TO-BOARD HEADER | TTI Europe |
| Connector, Header, 4Pos, 1Row, 1.5Mm | Newark Electronics |
| Connector: wire-board | TME |
| Molex Einbau-Stiftleiste (Standard) Polzahl Gesamt 4 Rastermaß: 1.5 mm 874380443 1 St. Tape on Full reel | Conrad |
| CUT TAPE - 1.5MM WTB HDR RA SMT T&R 2.54 NLF 4CKT | Heilind Americas |
| HEADER 1.50MM PICO-SPOX WTB, SMT, RA,4W | RS Americas |
| 04P PICO-SPOX W/B HEAD 90° | Rutronik |
| MOLEX 87438-0443 Pico-SPOX W-to-B Header 4p, 90° SMT, Pitch 1.5mm | Compona |
| Headers & Wire Housings 1.50MM HDR 04P RA SMT SHROUD | Sager |
| 1.5MM WTB HDR RA SMT T&R 2.54 NLF 4CKT | Heilind Europe |
