APT2X101D120J by Microchip Technology
1200V Ultrafast Soft Recovery Rectifier Diode
| Status: | Active |
|---|---|
| Series: | FRED-1200V |
| RoHS: | Compliant |
Microchip offers four series of discrete diode products: the medium-speed medium Vf D series, the high-speed DQ series, the silicon Schottky S series and the SiC Schottky MSCxxxSDxxxx series. These series of diodes are designed to provide high-quality solutions to a wide range of high-voltage, high-power application requirements, ranging from fast recovery for continuous conduction mode power factor correction to low conduction loss for output rectification.
FRED-1200V is a family of 1200V Ultrafast Soft Recovery Rectifier Diode available in a variety of current and package options.
Where to Buy
Prices starting from US$30.98
| Distributor | Stock | ||
|---|---|---|---|
|
Newark Electronics
from US$32.82
|
0
in stock
|
Buy Now |
|
Future Electronics
from US$33.23
|
0
in stock
|
Buy Now |
|
TME
from US$41.75
|
0
in stock
|
Buy Now |
|
Microchip Technology
from US$30.98
|
0
in stock
|
Buy Now |
|
Richardson RFPD
from US$35.26
|
0
in stock
|
Buy Now |
|
EBV Elektronik
-
|
0
in stock
|
Buy Now |
|
Avnet Silica
-
|
0
in stock
|
Buy Now |
| Buy Now |
Features
| Ultrafast recovery times |
| Soft recovery |
| Low leakage current |
| Avalanche energy rated |
| AEC-Q101 qualified (FRED DQ in TO-247, TO-220 and TO-264) |
| Higher switching frequency |
| Low switching losses |
| Low noise (EMI) switching |
| Easy to parallel |
| Improved system reliability |
| AC-DC/DC-DC converters |
| Inverters |
| Switch mode power supply |
| H/EV chargers |
| H/EV onboard chargers & powertrain |
Specifications
| Product Type | Silicon Discrete Diode |
|---|---|
| Forward Voltage (V) [typ] (V) | 2.0 - 2.8 |
| Package Type | SOT-227, TO-220, TO-247, TO-268 |
Last 6 months Inventory & Pricing History
Resources
Product Line Documents |
|---|
| High-Voltage Power Discretes and Modules |
Environmental Information
| JEDEC Indicator | N/A |
|---|---|
| ROHS | Compliant |
| China EFUP | Unknown |
| Device Weight (g) | 29.2 |
| Shipping Weight (kg) | 0.0463 |
| Lead Count | N/A |
| Package Type | N/A |
| Package Width or Size | 12x38.1x25.3 mm |
| Soldering Composition | N/A |
Alternative Descriptions
| Fred D 1200 V 100 A Dual Parallel Sot-227 4 Sot-227 Tube Rohs Compliant: Yes |Microchip Technology APT2X101D120J | Newark Electronics |
| APT2X101 Series 1200 V 93 A Ultrafast Soft Recovery Rectifier Diode - SOT-227 | Future Electronics |
| Module: diode | TME |
| FRED D 1200 V 100 A Dual Parallel SOT-227 | Microchip Technology |
| Diode Switching 1.2KV 93A 4-Pin SOT-227 Tube | Richardson RFPD |
