LT1585ACT-3.3#PBF Positive Linear Regulators (LDO) by Analog Devices
| Status: | Production |
|---|---|
| Series: | LT1585A-3.3 |
| RoHS: | Unknown |
Where to Buy
Prices starting from US$5.81
Features
| Fast Transient Response |
| Guaranteed Dropout Voltage at Multiple Currents |
| Load Regulation: 0.05% Typ |
| Trimmed Current Limit |
| On-Chip Thermal Limiting |
| Standard 3-Pin Power Package |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| 5A L Drop Fast Resp Pos Regs A | Analog Devices |
| Ldo, Fixed, 3.3V, 5A, To-220-3, 125Deg C | Newark Electronics |
| LDO, FIXED, 3.3V, 5A, TO-220-3, 125DEG C | element14 |
| LDO Regulator Pos 3.3V 5A 3-Pin(3+Tab) TO-220 Tube | Richardson RFPD |
LT1585ACT-3.3#PBF Power Management ICs - PMIC by Linear Technology
V REG 3.3V 5A 0.05% 3TO220
| Status: | Unknown |
|---|---|
| Series: | 3.3V 5A LDO Voltage Regulators |
| RoHS: | Unknown |
Specifications
| Output Type | Fixed |
|---|---|
| Input Voltage Min | 4.3V |
| Input Voltage Max | 7V |
| Fixed Output Voltage Nom. | 3.3V |
| Adjustable Output Voltage Min | - |
| Adjustable Output Voltage Max | - |
| Output Current | 5A |
| Dropout Voltage Vdo | 1.2V |
| LDO Regulator Case Style | TO-220 |
| No. of Pins | 3Pins |
| Operating Temperature Min | 0°C |
| Operating Temperature Max | 125°C |
| Product Range | 3.3V 5A LDO Voltage Regulators |
| Automotive Qualification Standard | - |
| RoHS Phthalates Compliant | Yes |
| MSL | - |
| SVHC | No SVHC (15-Jan-2018) |
| No. of Outputs | 1Outputs |
| Operating Temperature Range | 0°C to +125°C |
| Output Voltage Nom. | 3.3V |
| Primary Input Voltage | 7V |
Frequently Asked Questions
Where can I find additional details, specifications and documents for a LT1585ACT-3.3#PBF?
Additional datasheets, footprints and schematics for LT1585ACT-3.3#PBF are listed on our Part Details page. You can also find images and similar parts to LT1585ACT-3.3#PBF on this page.
What pricing and inventory information can I view?
Distributor pricing and stock information is available for LT1585ACT-3.3#PBF on our Product Comparison page. Access via the 'View Pricing & Stock' button to view LT1585ACT-3.3#PBF price breaks, MOQs, lead times, inventory and SKUs from distributors.
What category does LT1585ACT-3.3#PBF fall under?
The LT1585ACT-3.3#PBF is listed under Positive Linear Regulators (LDO).
Can I view similar or alternative parts?
You can view similar parts to LT1585ACT-3.3#PBF when available in the Positive Linear Regulators (LDO) range under the specifications section at the bottom of the details page.
Who can I contact for technical support of the product?
Submit any questions directly to the customer support team of the distributor listing the product. For the LT1585ACT-3.3#PBF you can contact the distributor directly for product support, shipping queries etc.
Is the LT1585ACT-3.3#PBF RoHS compliant?
This part has not been flagged as RoHS Compliant.
Which authorised distributors for LT1585ACT-3.3#PBF have stock available?
Authorised distributors including Analog Devices, Newark Electronics, element14, Farnell and Richardson RFPD have stock available or on a lead time for LT1585ACT-3.3#PBF.
How do I check stock and lead times for all distributors?
Stock availability and lead times will be displayed for LT1585ACT-3.3#PBF often in real-time on the comparison pages.
What if I can't find stock of LT1585ACT-3.3#PBF?
You can fill out our help required form which you can use to request a quote for LT1585ACT-3.3#PBF from some of our verified obsolescence suppliers. Alternatively, contact us via our web chat in the bottom left of your screen and one of our team will try to help.
