LTC6253IMS-7#PBF Rail-to-Rail Op Amps by Analog Devices

Rail-to-Rail Op Amps
Status: Production
Series: LTC6253-7
RoHS: Compliant
Download Datasheet Visit Manufacturer Site View Pricing & Stock
The LTC6253-7 is a dual high speed, low power, rail-to-rail input/output operational amplifier. On only 3.5mA of supply current, it features a 2GHz gain-bandwidth product, 500V/μs slew rate and a low 2.75nV/√Hz of input-referred noise. The combination of high bandwidth, high slew rate, low power consumption and low broadband noise makes the LTC6253-7 ideal for lower supply voltage, high speed signal conditioning systems. The device is stable for closed loop noise gains of 7 or higher.The LTC6253-7 maintains high efficiency performance from supply voltage levels of 2.5V to 5.25V and is fully specified at supplies of 2.7V and 5.0V.For

No distributors results available

Features

Gain Bandwidth Product: 2GHz
–3dB Frequency (AV = 7): 160MHz
Low Quiescent Current: 3.5mA Max
High Slew Rate: 500V/μs
Input Common Mode Range Includes Both Rails
Output Swings Rail-to-Rail
Low Broadband Voltage Noise: 2.75nV/√Hz
Fast Output Recovery
Supply Voltage Range: 2.5V to 5.25V
Input Offset Voltage: 350μV Max
Large Output Current: 90mA
CMRR: 105dB
Open Loop Gain: 60V/mV
Operating Temperature Range: –40°C to 125°C
MS10 Package with Independent Shutdown Pins

LTC6253IMS-7#PBF Amplifiers & Comparators by Linear Technology

OP-AMP DUAL 2GHZ 500V/US MSOP-10

Semiconductors - ICs>Amplifiers & Comparators>Operational Amplifiers - Op Amps
Status: Unknown
Series: -
RoHS: Unknown
Download Datasheet Visit Manufacturer Site View Pricing & Stock

Specifications

No. of Amplifiers 2 Amplifier, 2Amplifiers
Bandwidth 720MHz
Slew Rate 280V/µs
Supply Voltage Range 2.5V to 5.25V
Amplifier Case Style MSOP
No. of Pins 10Pins
Operating Temperature Min -40°C
Operating Temperature Max 85°C
Product Range -
Automotive Qualification Standard -
RoHS Phthalates Compliant Yes
MSL MSL 1 - Unlimited
SVHC No SVHC (15-Jan-2018)
