MAX4810CTN+ Medical Ultrasound Switches and Pulsers by Analog Devices

Medical Ultrasound Switches and Pulsers
Status: Production
Series: MAX4810
RoHS: Compliant
Download Datasheet Visit Manufacturer Site View Pricing & Stock
The MAX4810/MAX4811/MAX4812 integrated circuits generate high-voltage, high-frequency, unipolar or bipolar pulses from low-voltage logic inputs. These dual pulsers feature independent logic inputs, independent high-voltage pulser outputs with active clamps and independent high-voltage supply inputs.The MAX4810/MAX4811/MAX4812 feature a 9Ω output impedance for the high-voltage outputs, and a 27Ω impedance for the active clamp. The high-voltage outputs are guaranteed to provide 1.3A output current.All devices use three logic inputs per channel to control the positive and negative pulses and active clamp. Also included are two independent enable inputs. Disabling EN ensures the output MOSFETs are not accidentally turned on during fast power-supply ramping. This allows for faster ramp times and smaller delays between pulsing modes. A low-power shutdown mode reduces power consumption to less than 1µA. All digital inputs are CMOS compatible.The MAX4810 includes clamp output overvoltage protection, while the MAX4811 features both pulser output and clamp output overvoltage protection. The MAX4812 does not provide overvoltage protection. See the Ordering Information/Selector Guide in the full data sheet.The MAX4810/MAX4811/MAX4812 are available in a 56-pin (7mm x 7mm), TQFN exposed-pad package and are specified over the 0°C to +70°C commercial temperature range.

Where to Buy

Prices starting from US$29.65

Distributor Stock
Logo for Newark
Newark Electronics
from US$29.65
0
in stock
 Buy Now
Logo for Farnell UK
Farnell
from US$30.12
0
in stock
 Buy Now
Buy Now

Last 6 months Inventory & Pricing History

MAX4810CTN+ - Integrated Circuits by Analog Devices

HIGH VOLTAGE DIGITAL PULSER TQFN-56

Semiconductors - ICs
> Special Function
Status: Unknown
Series: -
RoHS: Unknown
Download Datasheet Visit Manufacturer Site View Pricing & Stock

Specifications

IC Function High Voltage Digital Pulser
Supply Voltage Min 2.7V
Supply Voltage Max 6V
IC Package Type TQFN
No. of Pins 56Pins
Operating Temperature Min 0°C
Operating Temperature Max 70°C
Product Range -
Automotive Qualification Standard -
MSL MSL 1 - Unlimited
SVHC No SVHC (15-Jan-2018)

Last 6 months Inventory & Pricing History

Alternative Descriptions

High Voltage Digital Pulser, Tqfn-56 | Newark Electronics
HIGH VOLTAGE DIGITAL PULSER, TQFN-56 | Farnell

Frequently Asked Questions

Where can I find additional details, specifications and documents for a MAX4810CTN+?

Additional datasheets, footprints and schematics for MAX4810CTN+ are listed on our Part Details page. You can also find images and similar parts to MAX4810CTN+ on this page.

What pricing and inventory information can I view?

Distributor pricing and stock information is available for MAX4810CTN+ on our Product Comparison page. Access via the 'View Pricing & Stock' button to view MAX4810CTN+ price breaks, MOQs, lead times, inventory and SKUs from distributors.

What category does MAX4810CTN+ fall under?

The MAX4810CTN+ is listed under Medical Ultrasound Switches and Pulsers.

Can I view similar or alternative parts?

You can view similar parts to MAX4810CTN+ when available in the Medical Ultrasound Switches and Pulsers range under the specifications section at the bottom of the details page.

Who can I contact for technical support of the product?

Submit any questions directly to the customer support team of the distributor listing the product. For the MAX4810CTN+ you can contact the distributor directly for product support, shipping queries etc.

Is the MAX4810CTN+ RoHS compliant?

Yes. This part has been flagged as RoHS Compliant by Analog Devices.

Which authorised distributors for MAX4810CTN+ have stock available?

Authorised distributors including Newark Electronics and Farnell have stock available or on a lead time for MAX4810CTN+.

How do I check stock and lead times for all distributors?

Stock availability and lead times will be displayed for MAX4810CTN+ often in real-time on the comparison pages.

What if I can't find stock of MAX4810CTN+?

You can fill out our help required form which you can use to request a quote for MAX4810CTN+ from some of our verified obsolescence suppliers. Alternatively, contact us via our web chat in the bottom left of your screen and one of our team will try to help.
