MCP6569-E/SL Amplifiers & Comparators by Microchip Technology
1.8V Low-Power Open-Drain Output Comparator
| Status: | Active |
|---|---|
| Series: | MCP6569 |
| RoHS: | Compliant |
Where to Buy
Prices starting from US$1.15
| Distributor | Stock | ||
|---|---|---|---|
|
Microchip Technology
from US$1.17
|
1,140
in stock
|
Buy Now |
|
Newark Electronics
from US$1.23
|
6
in stock
|
Buy Now |
|
element14
from US$1.34
|
6
in stock
|
Buy Now |
|
Farnell
from US$1.15
|
6
in stock
|
Buy Now |
|
EBV Elektronik
-
|
57
in stock
|
Buy Now |
|
Future Electronics
from US$1.30
|
0
in stock
|
Buy Now |
|
Avnet America
from US$1.30
|
0
in stock
|
Buy Now |
|
Avnet Silica
-
|
0
in stock
|
Buy Now |
| Buy Now |
Features
| Quad, Open Drain Outputs |
| 47ns Propagation Delay |
| Low Operating Voltage, 1.8V to 5.5V |
| Low Operating Current, 100uA (typical) |
| Small 14-pin TSSOP Package |
| AEC-Q100 Grade 1 |
Specifications
| # of Channels | 4 |
|---|---|
| Typical Prop Delay (ns) | 47 |
| Output Type | Open Drain |
| Supply Voltage Min. (V) | 1.8 |
| Supply Voltage Max. (V) | 5.5 |
| Iq Typical (µA) | 100 |
| Iq Max (µA) | 130 |
| Vos Max. (µV) | 10000 |
| Operating Temperature Range (°C) | -40 to 125 |
| Pins | Packaging | 14 | SOIC |
| Temp Range | -40C to +125C |
| Packing Media | Tube (57) |
