MIC38C45YM-TR More Semiconductors - ICs by Microchip Technology
20V, Current Mode SMPS Controller Family with Various UVLO and Max Duty Cycle
| Status: | Active |
|---|---|
| Series: | MIC38C45 |
| RoHS: | Compliant |
Where to Buy
Prices starting from US$0.98
| Distributor | Stock | ||
|---|---|---|---|
|
Newark Electronics
from US$1.39
|
1,813
in stock
|
Buy Now |
|
element14
from US$1.19
|
1,813
in stock
|
Buy Now |
|
Farnell
from US$1.17
|
1,813
in stock
|
Buy Now |
|
Future Electronics
from US$1.04
|
0
in stock
|
Buy Now |
|
TME
from US$1.02
|
0
in stock
|
Buy Now |
|
Microchip Technology
from US$0.98
|
0
in stock
|
Buy Now |
|
EBV Elektronik
-
|
0
in stock
|
Buy Now |
|
Avnet Silica
-
|
0
in stock
|
Buy Now |
| Buy Now |
Features
| Fast 40ns output rise and 30ns output fall times |
| -40°C to +85°C temperature range meets UC284x specifications |
| High-performance, low-power BiCMOS Process |
| Ultra-low start-up current (50µA typical) |
| Low operating current (4mA typical) |
| CMOS outputs with rail-to-rail swing |
| =500kHz current-mode operation |
| Trimmed 5V bandgap reference |
| Pin-for-pin compatible with UC3842/3843/3844/3845(A) |
| Trimmed oscillator discharge current |
| UVLO with hysteresis |
| Low cross-conduction currents |
Specifications
| Supported Topologies | Forward,Flyback |
|---|---|
| Supported Outputs | 1 |
| Minimum Input Voltage (V) | 7.6 |
| Maximum Input Voltage (V) | 20 |
| Typical Tolerance (%) | ±2 |
| Duty Cycle Max (%) | 0.5 |
| Internal Voltage Bias | True |
| Input UVLO Typ (V) | 8.4 |
| Operating Supply Current (mA) | 4 |
| Package | 8/PDIP, 8/SOIC, 8/MSOP 14/PDIP, 14/SOIC |
| Pins | Packaging | 8 | SOIC |
| Temp Range | -40C to +85C |
| Packing Media | Tape and reel (2500) |
Last 6 months Inventory & Pricing History
Environmental Information
| JEDEC Indicator | e4 |
|---|---|
| ROHS | Compliant |
| China EFUP | Compliant |
| Device Weight (g) | 0.075 |
| Shipping Weight (kg) | 0.25 |
| Lead Count | 8 |
| Package Type | SOIC |
| Package Width or Size | 3.90mm(.150in) |
| Soldering Composition | NiPdAu |
Alternative Descriptions
| Pwm Controller, Current Mode, Soic-8 | Newark Electronics |
| PWM CONTROLLER, CURRENT MODE, SOIC-8 | element14 |
| MIC38C45 Series 6 mA 500 kHz SMT BiCMOS Current-Mode PWM Controller - SOIC-8 | Future Electronics |
| IC: PMIC | TME |
| Monolithic SMPS Controller | Microchip Technology |
