SY100EP195VTG More Semiconductors - ICs by Microchip Technology
| Status: | Active |
|---|---|
| Series: | SY100EP15V |
| RoHS: | Compliant |
AC performance is guaranteed over the industrial –40°C to +85°C temperature range and 3.3V to 5V supply voltage. This device will operate in PECL/LVPECL or ECL/LVECL mode. For clock applications, the high-speed design combined with an extremely fast rise/fall time of less than 225ps produces a toggle frequency as high as 2.5GHz (~400mVPP swing).A VBB output reference pin is available for AC–coupled and single-ended input applications. In addition, a synchronous output enable function is provided.The SY100EP15V is part of Micrel’s high-speed, precision edge timing and distribution family.
For applications that require a different I/O combination, consult Micrel's website and choose from a comprehensive product line of high-speed, low-skew fanout buffers, translators, and clock dividers.
Where to Buy
Prices starting from US$7.08
| Distributor | Stock | ||
|---|---|---|---|
|
Microchip Technology
from US$7.08
|
500
in stock
|
Buy Now |
|
Newark Electronics
from US$8.11
|
175
in stock
|
Buy Now |
|
element14
from US$8.84
|
175
in stock
|
Buy Now |
|
Farnell
from US$8.12
|
173
in stock
|
Buy Now |
|
Future Electronics
from US$7.16
|
0
in stock
|
Buy Now |
|
Avnet America
from US$7.18
|
0
in stock
|
Buy Now |
|
EBV Elektronik
-
|
0
in stock
|
Buy Now |
|
Avnet Silica
-
|
0
in stock
|
Buy Now |
| Buy Now |
Features
| High-speed 1:4 PECL/ECL fanout buffer |
| 2:1 multiplexer input |
| >2.5GHz fMAX (toggle) |
| <225ps rise/fall times |
| <25ps within device skew |
| <425ps propagation delay (CLK-to-Q) |
| <1psRMS cycle-to-cycle jitter |
| <20psPP total jitter |
| Flexible power supply: 3.3V/5V |
| Wide operating temperature range: –40°C to +85°C |
| VBB reference for AC-coupled or single-ended applications |
| Output enable/disable function |
| 100K PECL/ECL compatible logic |
| Input accepts PECL/LVPECL/ECL/HSTL logic levels |
| Available in a 16-pin TSSOP package |
Specifications
| Product Type | Fanout & Buffer and Drivers |
|---|---|
| Description | 2:5 |
| Input | PECL, LVPECL, ECL, HSTL |
| Output | LVPECL |
| Supply Voltage | 2.5/3.3/5 |
| Max Freq (GHz) | 2.5 |
| Max Data (Gbps) | 0 |
| Max Prop Delay (ps) | 425 |
| Icc (mA) | 75 |
| Power Supply | 0 |
| Max Within Device Skew (ps) | 25 |
| OE | True |
| RPE | False |
| FSI | False |
| Input Mux | True |
| Input EQ | False |
| Delay Resolution ps/step | 0 |
| Output Type | LVPECL |
| Number Of Outputs | 0 |
| Pins | Packaging | 32 | TQFP |
| Temp Range | -40C to +85C |
| Packing Media | Tray (250) |
